凯斯零件查询(FLX3300B) - FLOATER - 2002 (9/02-10/03) (06-003) - HYDRAULIC COOLER GROUP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
812 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
280129
|
[2] |
NUT,1/4"-20
|
NH
|
| 1. |
276-14712
|
[1] |
SELF-TAP SCREW,Hex Hd, 1/4" x 3/4"
|
CAS
Superseded by part number: 87343649
|
| 2. |
BN302577
|
[1] |
ELBOW
|
BN
20Mor-20Mbx90
|
| 3. |
BN305058
|
[1] |
FITTING
|
BN
20Mor-24Mb
|
| 4. |
BN305539
|
[1] |
FITTING
|
BN
20Fb-24Mb
|
| 5. |
BN315654
|
[1] |
OIL COOLER
|
BN
Hydraulic
|
| 6. |
87529236
|
[4] |
WASHER,0.28" ID x 0.62" OD x 0.07" Thk
|
BN
0.281 X 0.625 X 0.065 HTS DOR HDN
|
| 7. |
BN315681
|
[1] |
HOSE
|
BN
Assembly, - 20 X 150"
|
| 8. |
BN50145
|
[4] |
WASHER
|
BN
3/8, Fw, G5 Superseded by part number: 87529312
|
| 9. |
86500692
|
[4] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 8, Full Thd
|
IMO
|
| 10. |
BN315699
|
[1] |
HOSE
|
BN
Assembly, -20 X 138"
|
| 11. |
BN316728
|
[1] |
PLATE
|
BN
Weldment, HYD CLR Mount, CS
|
| 12. |
BN316727
|
[1] |
PLATE
|
BN
Weldment, HYD CLR Mount, RS
|
| 13. |
9707580
|
[2] |
BOLT,Hex, 1/4" - 20 x 3/4", Gr 5, Full Thd
|
NH
|
