Pos.	Part No	Qty	Parts name	Comments
. .	ZE13Q08000	[1]	FLANGE	KOB4-BOLT FLANGE CAPS, (NOM. SIZE)/DIM A: 12.7(1/2")
. .	ZE13Q12000	[1]	PLUG	KOB4-BOLT FLANGE CAPS, (NOM. SIZE)/DIM A: 19.1(3/4")
. .	ZE13Q16000	[1]	PLUG	KOB4-BOLT FLANGE CAPS, (NOM. SIZE)/DIM A: 25.4(1.0")
. .	ZE13Q20000	[1]	PLUG	KOB4-BOLT FLANGE CAPS, (NOM. SIZE)/DIM A: 31.8(1.25")
. .	ZE13Q24000	[1]	FLANGE	KOB4-BOLT FLANGE CAPS, (NOM. SIZE)/DIM A: 38.1(1.50")
. .	ZE13Q32000	[1]	FLANGE	KOB4-BOLT FLANGE CAPS, (NOM. SIZE)/DIM A: 50.8(2.0")
. .	2445Z831D1	[1]	O-RING	KOB4-BOLT FLANGE CAPS, (NOM. SIZE)/DIM A: 18.24(.72"), DIM B: 40.49(1.59")
. .	ZD12P02600	[1]	O-RING	KOB4-BOLT FLANGE CAPS, (NOM. SIZE)/DIM A: 23.80(.94"), DIM B: 50.80(2.00")
. .	ZD12P03400	[1]	O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro	KOB4-BOLT FLANGE CAPS, (NOM. SIZE)/DIM A: 27.76(1.09"), DIM B: 57.15(2.25")
. .	ZD12P03800	[1]	O-RING	KOB4-BOLT FLANGE CAPS, (NOM. SIZE)/DIM A: 31.75 (1.25"), DIM B: 66.68(2.62")
. .	ZD12P04800	[1]	O-RING,3.5mm Thk x 47.7mm ID	KOB4-BOLT FLANGE CAPS, (NOM. SIZE)/DIM A: 36.50(1.44"), DIM B: 79.38(3.12")
. .	2445Z831D2	[1]	O-RING	KOB4-BOLT FLANGE CAPS, (NOM. SIZE)/DIM A: 44.45(1.75"), DIM B: 96.82(3.81")
. .	ZS18C08030	[1]	SCREW,Hex, M8 x 30mm	KOB4-BOLT FLANGE CAPSCREWS, (NOM. SIZE)/DIM A: 18.24(.72"), DIM B: 40.49(1.59")
. .	ZS18C10035	[1]	SCREW,Hex, M10 x 35mm	KOB4-BOLT FLANGE CAPS, (NOM. SIZE)/DIM A: 23.80(.94"), DIM B: 50.80(2.00")
. .	ZS18C12040	[1]	SCREW,Hex, M12 x 40mm	KOB4-BOLT FLANGE CAPS, (NOM. SIZE)/DIM A: 27.76(1.09"), DIM B: 57.15(2.25")
. .	ZS18C14045	[1]	CAP,Hex, M14 x 45mm	KOB4-BOLT FLANGE, (NOM. SIZE)/DIM A: 31.75(1.25"), DIM B: 66.68(2.62")
. .	ZS18C16050	[1]	SCREW,Hex, M16 x 50mm	KOB4-BOLT FLANGE, (NOM. SIZE)/DIM A: 36.50(1.44"), DIM B: 79.38(3.12")
. .	ZS18C20065	[1]	SCREW,Hex, M20 x 65mm	KOB4-BOLT FLANGE CAPS, (NOM. SIZE)/DIM A: 44.45(1.75"), DIM B: 96.82(3.81")
. .	ZW26X08000	[1]	LOCK WASHER	KOBLock -- ID 08 x OD 15 x Th 2.0mm, 4-BOLT FLANGE CAPS, (NOM. SIZE)/DIM A: 18.24(.72"), DIM B: 40.49(1.59") Superseded by part number: 83990583
. .	ZW26X10000	[1]	LOCK WASHER	KOBID 10 x OD 18 x Th 2.5mm, 4-BOLT FLANGE CAPS, (NOM. SIZE)/DIM A: 23.80(.94"), DIM B: 50.80(2.00")
. .	ZW26X12000	[1]	LOCK WASHER	KOB4-BOLT FLANGE CAPS, (NOM. SIZE)/DIM A: 27.76(1.09"), DIM B: 57.15(2.25")
. .	ZW26X14000	[1]	WASHER	KOB4-BOLT FLANGE CAPS, (NOM. SIZE)/DIM A: 31.75(1.25"), DIM B: 66.68(2.62")
. .	ZW26X16000	[1]	LOCK WASHER	KOB4-BOLT FLANGE CAPS, (NOM. SIZE)/DIM A: 36.50(1.44"), DIM B: 79.38(3.12")
. .	ZW26X20000	[1]	LOCK WASHER	KOB4-BOLT FLANGE CAPS, (NOM. SIZE)/DIM A: 44.45(1.75"), DIM B: 96.82(3.81")
. .	ZS23C08030	[1]	SCREW,Hex Socket Head, M8 x 30mm	KOB4-BOLT FLANGE, (NOM. SIZE)/DIM A: 18.24(.72"), DIM B: 40.49(1.59") Superseded by part number: ZS28C08030
. .	ZS23C10035	[1]	SCREW,Hex Socket Head, M10 x 35mm	KOB4-BOLT FLANGE CAPS, (NOM. SIZE)/DIM A: 23.80(.94"), DIM B: 50.80(2.00")
. .	ZS23C12040	[1]	SCREW,Hex Socket Head, M12 x 40mm	KOB4-BOLT FLANGE CAPS, (NOM. SIZE)/DIM A: 27.76(1.09"), DIM B: 57.15(2.25")
. .	ZS23C14045	[1]	SCREW,Hex Socket Head, M14 x 45mm	KOB4-BOLT FLANGE CAPS, (NOM. SIZE)/DIM A: 31.75(1.25"), DIM B: 66.68(2.62") Superseded by part number: ZS28C14045
. .	ZS23C16050	[1]	CAPSCREW,Hex Socket Head, M16 x 50mm	KOBSCREW 4-BOLT FLANGE CAPS, (NOM. SIZE)/DIM A: 36.50(1.44"), DIM B: 79.38(3.12")
. .	ZS23C20065	[1]	SCREW,Hex Socket Head, M20 x 65mm	KOB4-BOLT FLANGE CAPS, (NOM. SIZE)/DIM A: 44.45(1.75"), DIM B: 96.82(3.81")
. .	ZW26K08000	[1]	LOCK WASHER	KOB4-BOLT FLANGE CAPS, (NOM. SIZE)/DIM A: 18.24(.72"), DIM B: 40.49(1.59")
. .	ZW26K10000	[1]	LOCK WASHER	KOB4-BOLT FLANGE CAPS, (NOM. SIZE)/DIM A: 23.80(.94"), DIM B: 50.80(2.00") Superseded by part number: 12581679
. .	ZW26K12000	[1]	LOCK WASHER	KOB4-BOLT FLANGE CAPS, (NOM. SIZE)/DIM A: 27.76(1.09"), DIM B: 57.15(2.25")
. .	ZW26K14000	[1]	LOCK WASHER	KOB4-BOLT FLANGE CAPS, (NOM. SIZE)/DIM A: 31.75(1.25"), DIM B: 66.68(2.62")
. .	ZW26K16000	[1]	LOCK WASHER	KOB4-BOLT FLANGE CAPS, (NOM. SIZE)/DIM A: 36.50(1.44"), DIM B: 79.38(3.12")
. .	ZW26K20000	[1]	WASHER	KOB4-BOLT FLANGE CAPS, (NOM. SIZE)/DIM A: 44.45(1.75"), DIM B: 96.82(3.81")
