神钢零件查询(SK160LC) - DYNAMIC ACERA EXCAVATOR 11/2000 ASN YM02U0101 (11/00-12/02) (00-010) - KOBELCO SPECIAL SPANNER WRENCHES for HYDRAULIC LINE CONNECTIONS Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
709 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2421T160 | [1] | BOX SPANNER | KOBKOBELCO SPECIAL SPANNER WRENCHES FOR HYDRAULIC LINE CONNECTIONS, TUBE DIA.: 15(.591), A: 24(1.06), B: 70(2.76), C: 22(.866), D: 12.7(.50), E: 8(.315), F: 40(1.57), G: 16(.630) |
| . . | 2421T138 | [1] | BOX SPANNER | KOBKOBELCO SPECIAL SPANNER WRENCHES FOR HYDRAULIC LINE CONNECTIONS, TUBE DIA.: 18(.709), A: 32(1.26), B: 70(2.76), C: 22(.866), D: 12.7(.50), E: 11(.433), F: 42(1.65), G: 19(.748) |
| . . | 2421T130 | [1] | BOX SPANNER | KOBKOBELCO SPECIAL SPANNER WRENCHES FOR HYDRAULIC LINE CONNECTIONS, TUBE DIA.: 22(.866), A: 36(1.42), B: 70(2.76), C: 22(.866), D: 12.7(.50), E: 11.5(.453), F: 48(1.89), G: 23(.906) |
| . . | 2421T115 | [1] | BOX SPANNER | KOBKOBELCO SPECIAL SPANNER WRENCHES FOR HYDRAULIC LINE CONNECTIONS, TUBE DIA.: 28(1.10), A: 41(1.614), B: 109(4.29), C: 22(.866), D: 12.7(.50), E: 14.5(.571), F: 60(2.36), G: 29(1.14) |
| . . | 2421T314 | [1] | BOX SPANNER | KOBKOBELCO SPECIAL SPANNER WRENCHES FOR HYDRAULIC LINE CONNECTIONS, TUBE DIA.: 35(1.38), A: 55(2.17), B: 90(3.54), C: 45(1.77), D: 20(.787), E: 20.5(.807), F: 81(3.19), G: 41(1.61) |
