凯斯零件查询(FLX3300B) - FLOATER - 2002 (9/02-10/03) (01-015[02]) - DOOR ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
946 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 0. |
BN315636
|
[1] |
MS Door Assembly '99 Cab Complete (Includes Ref. 2 Through 9)
|
|
| 0. |
BN315907
|
[1] |
DOOR
|
BN
SS Assembly '99 Cab Complete (Includes Ref. 2 Through 9)
|
| 1. |
BN315926
|
[1] |
DOOR
|
BN
MS Frame, Door (For Door Assembly 315636)
|
| 1A. |
BN315927
|
[1] |
SS Frame, Door (For Door Assembly 315907)
|
|
| 2. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Swing Out Window, See Fig 01-017
|
| 3. |
BN313665
|
[1] |
EXTENSION
|
BN
Weldment, Release
|
| 4. |
BN314492
|
[1] |
COVER
|
BN
ABS
|
| 5. |
BN314491
|
[1] |
FOAM INSULATION
|
BN
|
| 6. |
BN313664
|
[1] |
LATCH
|
BN
Cam, Cab, FLX
|
| 7. |
BN2406306-017
|
[1] |
ROLL PIN
|
BN
3/16 X 1/2
|
| 8. |
BN66106
|
[1] |
HANDLE
|
BN
Outside
|
| 9. |
BN315637
|
[1] |
SEAL
|
BN
Bulb, Window Titan
|
| 10. |
BN315638
|
[1] |
DOOR SEAL
|
BN
Bulb, Titan Cab
|
| 11. |
BN315639
|
[1] |
RETAINER
|
BN
Seal Titan Door
|
| 12. |
R51754
|
[1] |
STRIKER
|
CAS
Door Striker
|
