凯斯零件查询(FLX3300B) - FLOATER - 2002 (9/02-10/03) (01-018) - GLASS & GASKET Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
740 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN314479
|
[1] |
GLASS
|
BN
Center
|
| 2. |
BN314482
|
[1] |
GLASS
|
BN
Front Side, RH
|
| 4. |
BN314483
|
[1] |
GLASS
|
BN
Rear
|
| 5. |
BN2406306-013
|
[2] |
ANGLE
|
BN
Corner SS Glass
|
| 6. |
BN2401306
|
[2] |
MOLDING
|
BN
Seal, Bulb, 90 Degree 23.5
|
| 7. |
BN314484
|
[3] |
TAPE
|
BN
Black BUTYL .312 SQ. 29'
|
| 8. |
BN314485
|
[3] |
SEALANT
|
BN
Adhesive, Urethane, No Primers 4.5'
|
| 9. |
BN314486
|
[1] |
SEALANT
|
BN
Urethane, HI Viscosity Black
|
| 10. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Glass, RH Side, See FiG 01-016
|
