卡特零件查询（735） 492-9136: WIRING GP-PAYLOAD
广数供应链运营团队, 15 02月, 2025，浏览：
119 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 459-0178 | [2] | LAMP GP-PAYLOAD SIGNAL(24-VOLT)(RED) | |
| | | | (EACH INCLUDES) |
| | 8T-8729 | | PIN-CONNECTOR(16-GA TO 20-GA) | |
| | 8T-8737 | [1] | PLUG-SEAL | |
| | 102-8803 | [1] | KIT-RECEPTACLE(3-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| 2. | 459-0179 | [2] | LAMP GP-PAYLOAD SIGNAL(24-VOLT)(GREEN) | |
| | | | (EACH INCLUDES) |
| | 8T-8729 | [2] | PIN-CONNECTOR(16-GA TO 20-GA) | |
| | 102-8802 | [1] | KIT-RECEPTACLE(2-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| 3. | 482-7529 | [1] | BEZEL AS | |
| 4. | 482-7530 | [1] | BEZEL AS | |
| 5. | 114-6658 | [6] | WASHER(6.5X17X1-MM THK) | |
| 6. | 8T-4971M | [6] | BOLT(M6X1X30-MM) | |
| 7. | 9X-7345 | [4] | GROMMET | |
| | M | | METRIC PART |
