| . . | YM10V00002F1 | [1] | PUMP | KOBNot serviced - Order upper assembly |
| 11. | YB10V00004R100 | [1] | REPAIR KIT | KOBPISTON ASSY(INCL REF 151 &152) Superseded by part number: YW10V00003S011 |
| 13. | YX10V00003R200 | [1] | REPAIR KIT | KOBCYLINDERASSY(R)(INCL REF 141 & 313) |
| 14. | YX10V00003R300 | [1] | REPAIR KIT | KOBCYLINDER ASSY (L)(INCL REF 141 &314) |
| 30. | YX10V00003R400 | [1] | REPAIR KIT | KOBPLATE ASSY, SWASH(INCL REF 212 & 214) |
| 111. | YX10V00003S111 | [1] | SHAFT | KOBSHAFT (F) |
| 113. | YX10V00003S113 | [1] | SHAFT | KOBSHAFT (R) |
| 116. | YX10V00003S116 | [1] | GEAR | KOBGEAR 1" |
| 123. | YX10V00003S123 | [2] | ROLLER BEARING | KOBBEARING, ROLLER |
| 124. | YW10V00005S124 | [2] | BEARING | KOBBEARING, NEEDLE |
| 127. | YW10V00003S127 | [1] | SPACER | KOBSPACER |
| 141. | NSS | [2] | NOT SOLD SEPARAT | CONBLOCK, CYLINDER |
| 151. | NSS | [18] | NOT SOLD SEPARAT | CONPISTON |
| 152. | NSS | [18] | NOT SOLD SEPARAT | CONSHOE |
| 153. | 2437U188S153 | [1] | PLATE | KOBPLATE |
| 156. | YW10V00005S156 | [2] | BUSHING | KOBBUSHING, SPHERICAL |
| 157. | 2437U188S157 | [18] | SPRING | KOBSPRING, CYLINDER |
| 211. | 2437U188S211 | [2] | PLATE | KOBPLATE, SHOE |
| 212. | NSS | [2] | NOT SOLD SEPARAT | CONPLATE, SWASH |
| 214. | NSS | [2] | NOT SOLD SEPARAT | CONBUSHING |
| 251. | 2437U188S251 | [1] | PLATE | KOBPLATE, RETAINER |
| 252. | YX10V00003S252 | [1] | SUPPORT | KOBSUPPORT (R) |
| 261. | 2437U188S261 | [1] | COVER | KOBCOVER (F) |
| 262. | YX10V00003S262 | [1] | COVER | KOBCOVER (R) |
| 271. | 2437U188S271 | [2] | CASING | KOBCASING, PUMP |
| 312. | YX10V00003S312 | [1] | BLOCK | KOBBLOCK, VALVE |
| 314. | NSS | [1] | NOT SOLD SEPARAT | CONPLATE, VALVE(L) |
| 401. | 2437U188S401 | [1] | CAPSCREW | KOBSCREW CAPSCREW(M16X175mm) |
| 406. | ZS23C06016 | [2] | SCREW,Hex Socket Head, M6 x 16mm | KOBM06x1.0x16mm Superseded by part number: ZS28C06016 |
| 466. | 2441U667S466 | [2] | PLUG | KOB1/4" PF |
| 467. | 2441U436S468 | [2] | PLUG | KOBPLUG(PF1/2) |
| 468. | YN30V00001S156 | [1] | PLUG | KOBPLUG(PF3/8) Superseded by part number: YW30V00001S156 |
| 490. | 2441U722S490 | [1] | PLUG | KOB1/16" NPTF |
| 530. | 2437U188S530 | [1] | REPAIR KIT | KOBPIN ASSY, TILTING(INCL REF 531 & 548) |
| 531. | NSS | [2] | NOT SOLD SEPARAT | CONPIN, TILTING |
| 532. | YX10V00003S532 | [2] | PISTON | KOBPISTON, SERVO |
| 534. | YX10V00003S534 | [1] | STOP | KOBSTOPPER (L) |
| 535. | 2437U188S535 | [1] | STOP | KOBSTOPPER(S) |
| 548. | NSS | [2] | NOT SOLD SEPARAT | CONPIN, FEED BACK |
| 702. | ZD12G03000 | [3] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOBID 29.4 ± 0.29 x OD 35mm |
| 710. | ZD12G08500 | [2] | O-RING,84.40mm ID x 90.60mm OD x 3.10mm | KOBID 84.40 ± 0.73 x OD 90mm |
| 711. | ZD12G09500 | [1] | O-RING,3.1mm Thk x 94.4mm ID, 90 Duro | KOBO-Ring -- ID 94.40 ± 0.81 x OD 100mm |
| 717. | ZD12G12000 | [1] | O-RING,3.1mm Thk x 119.4mm ID, 90 Duro | KOBO-Ring -- ID 119.40 ± 0.98 x OD 125mm |
| 719. | ZD12G11500 | [1] | O-RING,114.40mm ID x 120.60mm OD x 3.10mm | KOBID 114.40 ± 0.94 x OD 120mm |
| 724. | ZD12P00800 | [2] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOBID 7.8mm x OD 9.7mm |
| 725. | ZD12P01100 | [2] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 727. | ZD12P01400 | [4] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 728. | ZD12P01800 | [3] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 732. | ZD12P01600 | [1] | O-RING | KOBID 15.80 ± 0.20 x OD 20mm |
| 774. | YX10V00003S774 | [1] | OIL SEAL | KOBSEAL, OIL Superseded by part number: YX10V00003S020 |
| 789. | ZD85P01600 | [1] | RING | KOBRING, BACK-UP |
| 792. | ZD85G03000 | [1] | BACK-UP RING | KOBID 30 x OD 35 x Th 1.25mm |
| 808. | ZN12C16010 | [2] | NUT | KOBNUT |
| 824. | ZR16X03500 | [2] | RING | KOBRetaining -- ID 32.20 x OD 35 x Th 1.6mm |
| 885. | 2441U436S886 | [1] | PIN | KOBPIN, VALVE PLATE |
| 886. | ZP26D06014 | [1] | PIN | KOBRoll -- OD 06 x 14mm Long |
| 901. | ZS91C01000 | [1] | BOLT | KOBEye -- M10x1.50x18mm |
| 953. | 2437U188S953 | [1] | CAP,M10 x 20mm | KOBSETSCREW |
| 954. | 2437U188S954 | [1] | SCREW | KOBSCREW |
| 981. | NA | [1] | NOT SERVICED | FORPLATE, NAME |
| 983. | 2437U407S983 | [1] | RIVET | KOBPIN |
