| . . | NSS | [1] | NOT SOLD SEPARAT | CONNAME PLATE INSTAL |
| . . | YN22T00128F1 | [1] | LABEL | KOBASSY(STD) |
| . . | YN22T00128F2 | [1] | NAME PLATE ASSY(MULTI) | |
| 2. | YN22T00189P1 | [1] | TYPE PLATE | KOBDecal, Kobelco Logo Superseded by part number: YN22T00244P1 |
| 3. | YN20T01221P1 | [2] | DANGER DECAL | KOBDecal, Danger, Do not use counterweight lifting eyes to lift whole machine… |
| 4. | 2432T6111 | [1] | LABEL | KOBDecal, Warning, When servicing or repairing machine. Keep surface free of oil… |
| 5. | YN20T01405P1 | [1] | LABEL | KOBDecal, Warning, Pressurized hot oil can cause burns. Depress stem or … |
| 7. | 2432P3055 | [1] | LABEL | KOBDecal, No Step |
| 8. | YN20T01003P2 | [2] | LABEL | KOBDecal, Danger, Keep clear of swing area … |
| 11. | YN20T01015P2 | [1] | LABEL | KOBDecal, Warning, Improper booster cable connection can cause an explosion… |
| 12. | YN20T01010P1 | [1] | LABEL | KOBDecal, Warning, Steam of hot coolant can cause injury or blindness… Superseded by part number: ZL11N00404 |
| 13. | YN20T01009P1 | [1] | LABEL | KOBDecal, Warning, Rotating parts can cause personal injury… Superseded by part number: ZL11N05204 |
| 15. | YN20T01220P1 | [1] | LABEL | KOBDecal, Caution, Engine may be hot which could cause burns… Superseded by part number: ZL11N00504 |
| 16. | YN20T01216P1 | [1] | LABEL | KOBDecal, Warning, Greasing Swing Bearing… |
| 17. | 2432P2689 | [1] | LABEL | KOBDecal, Greasing Swing Bearing … |
| 18. | YN20T01213P1 | [1] | LABEL | KOBDecal, Diesel Fuel Only |
| 20. | YN20T01097P1 | [1] | LABEL | KOBDecal, Filled with antifreeze This machine is filled with … |
| 21. | 2432P3379 | [1] | LABEL | KOBDecal, Notice, Lack of Hydraulic Oil will cause damage to Main Hydraulic pump… |
| 22. | 2432T5613 | [1] | IDENTITY PLATE | KOBName plate, Kobelco - Model, Serial number, Manufacture year |
| 23. | 4020Z64 | [4] | RIVET | KOBOD 5.0 x 6.0mm Long Superseded by part number: 2420P623D7 |
| 24. | YN20T01290P2 | [1] | LABEL | KOBDecal, Caution - Hydraulic oil can be hot after machine operation. …, F1 ONLY |
| 25. | YN20T01012P1 | [1] | CAUTION DECAL | KOBDecal, Caution, Rotating engine fan, hot engine parts and drive belt can cause … |
| 26. | 2432T6573 | [1] | LABEL | KOBDecal, Hydraulic Oil |
| 27. | YN20T01338P1 | [1] | LABEL | KOBDecal, Warning, Electric Hazard may cause injury… |
| 28. | YN20T01028P1 | [1] | LABEL | KOBDecal, Lift eyes or tank can fail when lifting tank containing fluids and … |
| 29. | YN20T01484P1 | [1] | LABEL | KOBDecal, Rotary Multi Control Lever-Lock Position and Control Pattern. …, F2 ONLY |
| 30. | YN20T01485P1 | [1] | LABEL | KOBDecal, SAE, F2 ONLY |
| 31. | YN20T01484P1 | [1] | LABEL | KOBDecal, Rotary Multi Control Lever-Lock Position and Control Pattern. …, F2 ONLY |
| 32. | YN20T01495P1 | [1] | WARNING DECAL | KOBDecal, Warning, California Proposition 65, battery … |
