凯斯零件查询(FLX3330B) - FLOATER (12/99-9/02) (10-014) - TAILLIGHT MOUNT ASSEMBLY (BARE CHASSIS ONLY) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
309 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN300364
|
[8] |
BOLT
|
BN
M6-1 X 25, HH, 8.8
|
| 2. |
380424
|
[4] |
NUT,M20 x 2.5, Cl 8
|
FOR
|
| 3. |
BN304417
|
[8] |
NUT
|
BN
M6-1, NLN, 10.9 Superseded by part number: 353308
|
| 4. |
BN300469
|
[4] |
BOLT
|
BN
M20-2.5 X 45, HH, 8.8
|
| 5. |
BN300488
|
[8] |
WASHER
|
BN
M6, Flat, 8.8 Superseded by part number: 87529302
|
| 6. |
BN300493
|
[8] |
WASHER
|
BN
M20, FW, G5
|
| 7. |
BN307190
|
[1] |
LIGHT
|
BN
dual- w/brake LH
|
| 8. |
BN307191
|
[1] |
LIGHT
|
BN
dual w/brake RH
|
| 9. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Harness, Rear Lights, Flex
|
| 10. |
BN313171
|
[1] |
MOUNTING PLATE
|
BN
CS
|
| 11. |
BN313172
|
[1] |
MOUNTING PLATE
|
BN
taillight, RS
|
| 12. |
BN313717
|
[2] |
EXTENSION
|
BN
Taillight
|
