凯斯零件查询(FLX3330B) - FLOATER (12/99-9/02) (07-014) - AIR MANIFOLD ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
426 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN1470402C
|
[2] |
FLANGE NUT
|
BN
NC 1/4-20 Flex Lock Superseded by part number: 280129
|
| 2. |
BN1666253
|
[3] |
PLUG
|
BN
Pipe 1/4 Sq. Hd. Superseded by part number: 217-504
|
| 3. |
BN1666255
|
[1] |
3/8 SQ. HD.
|
|
| 4. |
BN1913353C
|
[2] |
HH 1/4-20 X 2 NC
|
|
| . . |
BN2292088
|
[6] |
AIR INTAKE TUBE
|
BN
3/8" Black Superseded by part number: 84422568
|
| 6. |
BN2393326
|
[1] |
COUPLING
|
BN
B32 Superseded by part number: 84172049
|
| 7. |
BN2399401
|
[2] |
ADAPTER
|
BN
Male, 1/4" Tube
|
| 8. |
BN2399404
|
[2] |
90 ELBOW
|
BN
1/4" MPT x 1/4" OD Tube, Push Lock Fitting
|
| 9. |
BN2399407
|
[1] |
PIPE FITTING
|
BN
Connector, Tube MT38038
|
| 10. |
BN2399410
|
[1] |
HYD CONNECTOR
|
BN
Tube ULC380
|
| 11. |
BN6092020
|
[1] |
Air
|
|
