| 1. |
J918986
|
[1] |
CRANKSHAFT
|
CAS
Assembly, New
|
| 1. |
JR918986
|
[1] |
REMAN-CRANKSHAFT
|
CAS
Assembly, Remanufactured, N.A. Only Superseded by part number: J918986R
|
| 1. |
JC918986
|
[1] |
CORE-CRANKSHAFT
|
CAS
Return Number
|
| 2. |
J918776
|
[1] |
GEAR
|
CAS
Superseded by part number: J918776AM
|
| 3. |
J904483
|
[1] |
PIN,6.01mm OD x 8mm L
|
CAS
Dowel
|
| 4. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Seal, Order : A77790
|
| 5. |
J925570
|
[1] |
DAMPER
|
CAS
Pulley
|
| 6. |
J906733
|
[4] |
BOLT,Hex Flg, M14 x 1.5 x 35mm, Cl 12.9
|
IH
hex flange, special, 14 x 35 mm
|
| 8. |
J921042
|
[1] |
REAR COVER
|
CAS
Retainer Superseded by part number: J933384
|
| 9. |
J914301
|
[1] |
GASKET
|
CAS
Mounting Superseded by part number: 87447962
|
| 10. |
87015915
|
[8] |
BOLT,Hvy Hex, M6 x 15mm, Cl 8.8, Full Thd
|
RAC
|
| 11. |
J945930
|
[6] |
BEARING SET
|
CAS
Crankshaft, Main, Upper and Lower Set, Standard
|
| 11. |
J945931
|
[6] |
BEARING SET
|
CAS
Crankshaft, Main, Upper And Lower Set, 0.25 mm Undersize
|
| 11. |
J945932
|
[6] |
BEARING SET
|
CAS
Main, Upper And Lower Set, 0.50 mm Undersize
|
| 11. |
J945933
|
[6] |
BEARING SET
|
CAS
Main, Upper And Lower Set, 0.75 mm Undersize
|
| 11. |
J945934
|
[6] |
BEARING SET
|
CAS
Main, Upper And Lower Set, 1.0 mm Undersize
|
| 12. |
J945929
|
[1] |
THRUST BEARING
|
CAS
Main Thrust, Upper And Lower Set, Standard Superseded by part number: J945929AM
|
| 12. |
J945922
|
[1] |
THRUST BEARING
|
CAS
Main Thrust, Upper and Lower Set, 0.25 mm Undersize
|
| 12. |
J945923
|
[1] |
THRUST BEARING
|
CAS
Main Thrust, Upper and Lower Set, 0.50 mm Undersize
|
| 12. |
J945924
|
[1] |
THRUST BEARING
|
CAS
Main Thrust, Upper and Lower Set, 0.75 mm Undersize
|
| 12. |
J945925
|
[1] |
THRUST BEARING
|
CAS
Main Thrust, Upper and Lower Set, 1.0 mm Undersize
|
| 12. |
J945926
|
[1] |
THRUST BEARING
|
CAS
Main Thrust, Upper and Lower Set, Standard JourNal Diameter, 0.25 mm Oversize Thrust Width
|
| 12. |
J945927
|
[1] |
THRUST BEARING
|
CAS
Main Thrust, Upper and Lower Set, Standard Journal Diameter, 0.50 mm Oversize Thrust Width
|
| 12. |
J945928
|
[1] |
THRUST BEARING
|
CAS
Main Thrust, Upper and Lower Set, 0.50 mm Undersize Journal Diameter, 0.50 mm Oversize Thrust Width
|
| 13. |
J918113
|
[1] |
SHIELD,74.73mm ID x 91.7mm OD x 6mm Thk
|
CAS
Order : A77790, (See Ref. 18)
|
| 14. |
A77790
|
[1] |
SEAL KIT
|
CAS
Oil, Crankshaft Front
|
| 19. |
A77808
|
[1] |
SERVICE KIT
|
CAS
Wear Sleeve, Crankshaft Front Superseded by part number: A77808AM
|
| 23. |
J924987
|
[1] |
SHIELD,77.14mm ID x 89.38mm OD x 6.35mm Thk
|
CAS
|
| 24. |
J353978
|
[1] |
SEAL PACKAGE
|
CAS
Replaces : A77809, Crank., Rear Superseded by part number: J934486
|
| 27. |
A77810
|
[1] |
SERVICE KIT
|
CAS
Wear Sleeve, Crankshaft Rear Superseded by part number: A77810AM
|
