神钢零件查询(SK160LC) - DYNAMIC ACERA EXCAVATOR 11/2000 ASN YM02U0101 (11/00-12/02) (01-020) - UPPER HYDRAULIC LINES (SWING PRIORITY) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
135 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM03H00002F1 | [1] | HYD LINES, UPPER | |
| 1. | ZG33F10008 | [1] | 90 ELBOW,1"-14 UNS x PF 1/2" | KOB90° -- 1" -14UNS x 1/2" PF (Incls. O-Ring ZD12P01800) |
| 2. | YY03H01015D1 | [1] | HOSE | KOB(1-14uns,L=500cm) |
| 3. | YY03H01019P1 | [1] | TUBE | KOB(1-14UNS) |
| 4. | HG23H10012G1 | [1] | HYD CONNECTOR | KOB1"-14UNS - 3/4"PT x 66.5mm Long (Incls. O-Ring ZD12P02400) |
| 4-1. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 5. | ZW16H10000 | [2] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 6. | ZD12A01600 | [3] | O-RING | KOBID 15.60 ± 0.12 x OD 19.16mm |
| 7. | ZC26X18011 | [1] | CLAMP | KOB Superseded by part number: ZC26M18011 |
| 8. | YY03H01020P1 | [1] | SUPPORT | |
| 9. | ZS18C10030 | [1] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| 10. | ZS18C10040 | [1] | SCREW,Hex, M10 x 40mm | KOBM10x1.50x40mm |
| 11. | ZE72X12000 | [1] | PLUG | KOB(3/4" PF) (Incls. O-Ring ZD12P02400) |
