神钢零件查询(SK160LC) - DYNAMIC ACERA EXCAVATOR 11/2000 ASN YM02U0101 (11/00-12/02) (01-024[01]) - OPERATORS CONTROLS Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
562 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN03M00045F1 | [1] | CONTROL | KOB |
| 1. | YN03M00044F1 | [1] | CONTROL | KOBSee P. 104-01-1 |
| 2. | YN50M00004F1 | [1] | LEVER | KOBSee P. 108-01-1 |
| 3. | YN03M01287P1 | [1] | COVER | KOBRH |
| 4. | YN03M01288P1 | [1] | COVER | KOBRH |
| 5. | YN03M01289P1 | [1] | COVER | KOBLH |
| 6. | YN03M01290P1 | [1] | COVER | KOBLH |
| 7. | YN03M01331P1 | [2] | BOOT | KOB |
| 8. | YN03M01328P2 | [2] | PLATE | KOB |
| 9. | YV03M01005P1 | [1] | PLATE | KOB |
| 10. | YN03M01369F2 | [1] | GRIP | KOBASSY, RH (ATT, BOOST) Superseded by part number: YN03M01510F2 |
| 10-2. | YN03M01359P1 | [1] | GRIP | KOB Superseded by part number: YN03M01510F2 |
| 10-5. | YN03M01362P1 | [1] | LEVER | KOB |
| 10-6. | YN50E00007P1 | [1] | SWITCH ASSY | KOB |
| 10-7. | YN03M01370P1 | [1] | BOLT | KOBM03x0.5x08mm (Incls. Washer) |
| 11. | YN03M01369F1 | [1] | GRIP | KOBASSY, LH (HORN) Superseded by part number: YN03M01510F1 |
| 11-1. | YN03M01358P1 | [1] | GRIP | KOB Superseded by part number: YN03M01510F1 |
| 11-4. | YN03M01361P1 | [1] | LEVER | KOB |
| 11-6. | YN50E00007P1 | [1] | SWITCH ASSY | KOB |
| 11-7. | YN03M01370P1 | [1] | BOLT | KOBM03x0.5x08mm (Incls. Washer) |
| 13. | YN03M01040P1 | [2] | GRIP | KOB |
| 15. | ZM46C06020 | [6] | BOLT | KOBM06x1.0x20mm (Incls. Washer & Lockwasher) |
| 16. | ZM22C10020 | [4] | BOLT | KOBM10x1.50x20mm (Incls. Washer & Lockwasher) |
| 17. | ZM22C10025 | [4] | BOLT | KOBM10x1.50x25mm (Incls. Washer & Lockwasher) |
| 18. | ZN18C14011 | [2] | NUT | KOBM14x2.0mm |
| 19. | 2420Z1232 | [2] | NUT | KOBM12x1.25mm |
| 20. | PH32H01007P1 | [2] | CLAMP | KOB |
| 21. | ZM22C10040 | [2] | BOLT | KOBM10x1.50x40mm (Incls. Washer & Lockwasher) |
