凯斯零件查询(FLX3330B) - FLOATER (12/99-9/02) (02-050) - AIR EXHAUST GROUP (FLX3300B CASE ENGINE) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
608 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
A170807
|
[1] |
CLAMP,102mm ID
|
CAS
4" T-Bolt
|
| 2. |
BN314410
|
[1] |
TUBE
|
BN
Exhaust
|
| 3. |
BN25927
|
[6] |
CLAMP,104.8mm ID
|
BN
4" Muffler
|
| 4. |
BN314752
|
[2] |
ELBOW
|
BN
90, Exhaust
|
| 5. |
BN303467
|
[1] |
HOSE,4.00" ID x 18.00"
|
BN
|
| 6. |
BN314753
|
[1] |
BRACKET
|
BN
Exhaust Hanger
|
| 7. |
BN314409
|
[1] |
TUBE
|
BN
Exhaust
|
| 8. |
BN303459
|
[1] |
PIPE CLAMP
|
BN
Muffler, 5"
|
| 9. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
14-1800 CFM
|
| 10. |
86528579
|
[8] |
NUT,M8 x 1.25
|
WIN
|
| 11. |
80043233
|
[8] |
SCREW
|
FOR
Hex, M8 x 20, 10.9 Superseded by part number: 43233
|
| 12. |
86624185
|
[8] |
WASHER,8.8mm ID x 17.5mm OD x 2mm Thk
|
FOR
|
| 13. |
BN314754
|
[2] |
BRACKET
|
BN
Exhaust Hanger
|
| 14. |
BN300390
|
[3] |
BOLT
|
BN
M10-1.5 X 30, HH, 8.8
|
| 15. |
BN300490
|
[3] |
BOLT
|
BN
M10, FW, 8.8 Superseded by part number: 86625252
|
| 16. |
BN304419
|
[3] |
NUT
|
BN
M10-1.5, NLN, 10.9 Superseded by part number: 100037
|
| 17. |
BN318814
|
[1] |
SHIELD
|
BN
Heat, 4" Elbow
|
