凯斯零件查询(FLX3330B) - FLOATER (12/99-9/02) (02-052) - MUFFLER ASSEMBLY (FLX3300B CASE ENGINE) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
334 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
BN311343
|
[1] |
MUFFLER
|
BN
(Complete) Superseded by part number: BN313591, BN313590, BN313588, BN313589, BN313593, 84289019
|
| 1. |
BN313588
|
[1] |
SHIELD
|
BN
Heat, Muffler
|
| 2. |
BN313589
|
[6] |
BOLT
|
BN
Heat Shield
|
| 3. |
BN313590
|
[2] |
CLAMP
|
BN
Heat Shield
|
| 4. |
BN313591
|
[1] |
EXHAUST SYSTEM PIPE
|
BN
Tail, Muffler
|
| 5. |
BN313592
|
[2] |
CLAMP
|
BN
Bent Bolt, 5" Superseded by part number: 84289019
|
| 6. |
BN313593
|
[1] |
MUFFLER
|
TYR
14-1800 CFM
|
