凯斯零件查询(FLX3330B) - FLOATER (12/99-9/02) (02-056) - BAFFLE ASSEMBLY (FLX3300B) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
776 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN1470402C
|
[3] |
FLANGE NUT
|
BN
1/4-20, FLN, G8 Superseded by part number: 280129
|
| 2. |
BN313961
|
[4] |
SCREW,Hex, 1/4" x 3/4", SST
|
BN
1/4" X 3/4", HH, STP, SS Superseded by part number: 87270117
|
| 3. |
BN315137
|
[1] |
BAFFLE
|
BN
Radiator, CS
|
| 4. |
BN315138
|
[1] |
BAFFLE
|
BN
Radiator, RS
|
| 5. |
BN315241
|
[1] |
BAFFLE
|
BN
Rad, Top
|
| 6. |
87529236
|
[3] |
WASHER,0.28" ID x 0.62" OD x 0.07" Thk
|
BN
0.281 X 0.625 X 0.065 HTS DOR HDN
|
