神钢零件查询(SK160LC) - DYNAMIC ACERA EXCAVATOR 11/2000 ASN YM02U0101 (11/00-12/02) (01-039) - FLOOR PLATE GROUP BREAKER) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
923 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN03M00033F3 | [1] | PLATE GROUP, FLOOR | |
| A3. | YN26M00021P1 | [1] | FLOOR MAT | KOB |
| A6. | YN03M01335P1 | [1] | SUPPORT | KOB |
| A7. | YN03M01364P3 | [1] | COVER | KOB |
| A8. | YN03M01062P1 | [2] | COVER | KOB Superseded by part number: YN03M01479P1 |
| A9. | 2420R603D6 | [1] | GROMMET | KOB |
| A10. | ZM27C08025 | [7] | BOLT | KOBM08x1.25x25mm (Incls. Washer & Lockwasher) |
| A11. | ZM22C10030 | [2] | BOLT | KOBM10x1.50x30mm (Incls. Washer & Lockwasher) |
| A12. | YN03M01365P1 | [1] | COVER | KOB |
| A13. | ZM27C08030 | [1] | SCREW | KOBM08x1.25x30mm (Incls. Washer & Lockwasher) |
| A14. | YT21C01037D6 | [1] | TRIM PANEL | KOB120mm Long (4-23/32 in) |
| B1. | YN03M00041P1 | [1] | FLOOR STAND | KOB Superseded by part number: YN03M00041P2 |
| . . | YN03M00023F1 | [1] | SPARE PART | KOB |
| C1. | YN03M01245P1 | [4] | ENGINE MOUNT | KOBRUBBER |
| C2. | ZM12C10030 | [16] | BOLT | KOBM10x1.50x30mm (Incls. Lockwasher) |
| C3. | ZW16H16000 | [4] | WASHER | KOBID 17 x OD 32 x Th 4.5mm |
| C4. | ZW26X16000 | [4] | LOCK WASHER | KOBID 16 x OD 28 x Th 4.0mm |
| C5. | ZN18C16013 | [4] | NUT | KOBM16x2.0mm |
