神钢零件查询(SK160LC) - DYNAMIC ACERA EXCAVATOR 11/2000 ASN YM02U0101 (11/00-12/02) (01-042) - FRONT WINDOW ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
792 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN50C00001F1 | [1] | WINDOW | KOBFRONT ASSY Superseded by part number: YN50C00003F4 |
| 1. | YN50C01012P1 | [1] | FRAME | KOBASSY Superseded by part number: YN50C01240P1 |
| 2. | YN02C01563P1 | [1] | GLASS | KOB Superseded by part number: YN02C01563P2 |
| 3. | YN50C01023P1 | [1] | SEAL | KOB |
| 4. | YJ21C01149P1 | [2] | CLIP | KOB |
| 5. | YT50C01020P1 | [3] | RETAINER | KOB |
| 6. | YT50C01042P1 | [2] | BLOCK | KOBTAPPED |
| 7. | YT50C01043P1 | [2] | PLATE | KOB |
| 8. | YN50C01030P1 | [1] | FLEXIBLE JOINT | KOB |
| 10. | YN50C01024P1 | [1] | SEAL | KOB834.4mm Long (32-55/64 in) Superseded by part number: YN50C01246P1 |
| 11. | YT50C01023P1 | [6] | RUBBER | KOB Superseded by part number: YN02C01176D3 |
| 12. | YR21C01161P1 | [3] | WASHER,9mm ID x 22mm OD x 2.3mm Thk | KOBID 09 x OD 22 x Th 2.3mm |
| 13. | YT50C01063F2 | [1] | HANDLE | KOBASSY, LH Superseded by part number: YT50C01086F2 |
| 13-2. | YT50C01065F1 | [1] | LEVER ASSY. | KOB |
| 13-2A. | YT50C01055P1 | [1] | LEVER ASSY. | KOB Superseded by part number: YN02C01386S003 |
| 13-2B. | YT50C01056P1 | [1] | LEVER | KOBASSY |
| 13-2C. | ZR36X00800 | [1] | SNAP RING | KOBSNAP |
| 13-3. | ZR36X00800 | [2] | SNAP RING | KOBSNAP |
| 13-4. | YT50C01059P1 | [1] | SHIM | KOB |
| 13-5. | YT50C01044F2 | [1] | HANDLE | KOBASSY Superseded by part number: YN50C01041F2 |
| 13-5B. | YT50C01053P1 | [1] | BRACKET | KOB |
| 13-5C. | YT50C01057P1 | [1] | SPRING | KOB |
| 13-5D. | ZR36X00800 | [1] | SNAP RING | KOBSNAP |
| 13-5E. | YT50C01058P1 | [1] | SHIM | KOB |
| 13-5F. | YN50C01032P1 | [1] | HANDLE ASSY | |
| 14. | YT50C01064F2 | [1] | HANDLE | KOBRH Superseded by part number: YT50C01087F2 |
| 14-2. | YT50C01065F1 | [1] | LEVER ASSY. | KOB |
| 14-2A. | YT50C01055P1 | [1] | LEVER ASSY. | KOB Superseded by part number: YN02C01386S003 |
| 14-2B. | YT50C01056P1 | [1] | LEVER | KOBASSY |
| 14-2C. | ZR36X00800 | [1] | SNAP RING | KOBSNAP |
| 14-3. | ZR36X00800 | [2] | SNAP RING | KOBSNAP |
| 14-4. | YT50C01059P1 | [1] | SHIM | KOB |
| 14-5. | YT50C01045F2 | [1] | HANDLE | KOBASSY Superseded by part number: YN50C01042F2 |
| 14-5B. | YT50C01054P1 | [1] | BRACKET | KOB |
| 14-5C. | YT50C01057P1 | [1] | SPRING | KOB |
| 14-5D. | ZR36X00800 | [1] | SNAP RING | KOBSNAP |
| 14-5E. | YT50C01058P1 | [1] | SHIM | KOB |
| 14-5F. | YN50C01033P1 | [1] | HANDLE ASSY | |
| 16. | YT50C01022P1 | [5] | SEAL,15mm ID x 30mm OD x 2mm Thk | KOB |
| 27. | YT02C01241D1 | [3] | BOLT | KOBM08x1.25x12mm |
| 28. | ZM66C06016 | [6] | BOLT | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) |
| 31. | ZW16X14000 | [3] | WASHER | KOBID 14 x OD 28 x Th 3.2mm |
| 33. | 2420T4505 | [6] | WASHER,7mm ID x 16mm OD x 1mm Thk | KOBID 07 x OD 16 x Th 1.0mm |
| 36. | ZR36X00800 | [2] | SNAP RING | KOBSNAP |
| 40. | YT50C01012P1 | [4] | ROLLER,27mm ID x 57mm OD x 51mm L | KOB |
| 42. | YN50C01027P1 | [1] | SEAL | KOB Superseded by part number: YN50C01035P1 |
