| 1. | YM22C00001F1 | [1] | ENGINE HOOD | KOBSee Figure 01-049 |
| 3. | YM21C01001F1 | [1] | PANEL | KOB |
| 3-1. | YM21C01003P1 | [1] | PANEL | KOB Superseded by part number: YM21C01130P2 |
| 3-1G. | YN21C01658P1 | [2] | HINGE | KOB |
| 3-1H. | 2427R703F2 | [1] | LOCK | KOB Superseded by part number: 2421R175F1 |
| 3-1J. | ZS11C10025 | [4] | CAP,Hex, M10 x 25mm, Cl 4.8 | KOBScrew -- M10x1.50x25mm Superseded by part number: ZS18C10025 |
| 3-2. | YM21C01005P1 | [1] | INSULATING PANEL | KOB |
| 3-3. | YN21C01674P1 | [1] | INSULATING PANEL | KOBRUBBER |
| 3-4. | YM21C01006P1 | [1] | INSULATING PANEL | KOB |
| 4. | YN21C01448F1 | [1] | PANEL | KOBASSY |
| 4-1. | YN21C01408P1 | [1] | PANEL | KOB |
| 4-1G. | YN21C01658P1 | [2] | HINGE | KOB |
| 4-1H. | 2427R703F1 | [1] | LOCK | KOB Superseded by part number: 2421R175F2 |
| 4-1J. | ZS11C10025 | [4] | CAP,Hex, M10 x 25mm, Cl 4.8 | KOBScrew -- M10x1.50x25mm Superseded by part number: ZS18C10025 |
| 4-2. | YN21C01449P1 | [1] | FOAM INSULATION | KOB |
| 4-3. | YN21C01675P1 | [1] | RUBBER | KOB |
| 4-4. | YN21C01450P1 | [1] | FOAM INSULATION | KOB |
| 4-5. | YN21C01814D1 | [1] | RUBBER | KOB06x40x53mm Long |
| 5. | YM21C01002F1 | [1] | PANEL | KOB |
| 5-1. | YM21C01007P1 | [1] | PANEL | KOB |
| 5-1F. | YN21C01658P1 | [2] | HINGE | KOB |
| 5-1G. | ZS11C10030 | [4] | CAPSCREW,Hex, M10 x 30mm, Cl 4.8 | KOBSCREW M10x1.50x30mm |
| 5-2. | YM21C01009P1 | [1] | FOAM INSULATION | KOB |
| 5-3. | YN21C01397D1 | [1] | RUBBER SLEEVE | KOB |
| 6. | YM21C01010P1 | [1] | PANEL | KOBASSY |
| 7. | YM21C01014F1 | [1] | COVER ASSY | KOBSee Figure 01-048 -- Date used 03/16/2000 - 12/09/2002 |
| . . | YN21C01832F1 | [1] | COVER | KOBSee Figure 01-048 -- Date used 12/09/02 - UP |
| 8. | YM21C01015P1 | [1] | GUARD | KOB |
| 9. | YM21C01038P1 | [1] | GUARD | KOB |
| 12. | YM21C01018P1 | [1] | GUARD | KOB |
| 13. | YM21C01039P1 | [1] | GUARD | KOB |
| 14. | YM21C01045P1 | [1] | BRACKET | KOB |
| 15. | YM21C01041P1 | [1] | BRACKET | KOB |
| 16. | YM21C01022P1 | [1] | BRACKET | BRACKET |
| 17. | YM21C01023P1 | [1] | BRACKET | |
| 18. | YM21C01024P1 | [1] | BRACKET | KOB |
| 21. | YM21C01025F1 | [1] | GUARD ASSY | |
| 21-1. | YM21C01046P1 | [1] | GUARD | KOB |
| 21-2. | YM21C01027P1 | [1] | INSULATING PANEL | KOB |
| 21-3. | YM21C01047P1 | [1] | FOAM INSULATION | KOB |
| 21-4. | YM21C01029P1 | [1] | INSULATING PANEL | KOB |
| 21-5. | 2420R429D11 | [2] | GROMMET | KOB |
| 21-6. | YN21C01397D2 | [1] | INSULATING PANEL | KOBRUBBER |
| 22. | YM21C01030F1 | [1] | GUARD ASSY | |
| 22-1. | YM21C01031P1 | [1] | GUARD | |
| 22-2. | YW21C01057DB | [1] | INSULATING PANEL | KOBSTRIP, WEATHER |
| 22-3. | YM21C01048P1 | [1] | INSULATION | |
| 23. | YM21C01044P1 | [1] | BRACKET | |
| 24. | YM21C01033P1 | [1] | GUARD | KOBGUARD |
| 25. | YN21C01714P1 | [2] | PLATE | KOB |
| 26. | YN21C01715P1 | [1] | STRIKER PLATE | KOB |
| 27. | YN21C01716P1 | [1] | PLATE | KOB |
| 28. | YM21C01035P1 | [1] | SPRING | KOB |
| 29. | YN21C01820P1 | [1] | HANDRAIL | KOBSTAY |
| 31. | 2416T6289D2 | [3] | STAY | KOBSTAY |
| 32. | 2419R9D2 | [3] | COTTER PIN | KOBOD 08mm x 27.7mm Long |
| 34. | YN21C01321P1 | [4] | STOP | KOB Superseded by part number: YN21C03212P1 |
| 35. | ZM32C12025 | [29] | BOLT | KOBM12x1.75x25mm (Incls. Washer & Lockwasher) |
| 36. | ZM32C12030 | [27] | BOLT | KOBM12x1.75x30mm (Incls. Washer & Lockwasher) |
| 37. | YN02C01299P1 | [10] | BOLT | KOBM12x1.75x35mm (Incls. Washer & Lockwasher) |
| 38. | ZS18C08025 | [18] | SCREW,Hex, M8 x 25mm | KOBM08x1.25x25mm |
| 40. | ZN18C08007 | [8] | NUT | KOBM08x1.25mm |
| 41. | ZN18C10008 | [12] | NUT | KOBM10x1.50mm |
| 42. | ZN18F10008 | [4] | NUT | KOBM10x1.25mm |
| 43. | ZN18C12010 | [4] | NUT | KOBM12x1.75mm |
| 44. | ZW26X08000 | [18] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 45. | ZW26X10000 | [12] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 46. | ZW26X12000 | [10] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 47. | ZW16X08000 | [14] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 48. | ZW16H08000 | [12] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| 50. | 2418T12346 | [12] | WASHER | KOBID 11 x OD 30 x Th 3.2mm |
| 51. | 2418T10357 | [10] | WASHER | KOBID 13 x OD 30 x Th 3.2mm Superseded by part number: 2418T12345 |
| 52. | 2427R475 | [1] | CATCH | KOB Superseded by part number: YN21C02226P1 |
| 53. | 2427R302D2 | [1] | CATCH | KOB |
| 55. | 2456R351 | [1] | MIRROR | KOB |
| 56. | 24100P3750F1 | [1] | STAY | KOBSTAY ASSY |
| 56-1. | 2416P18523 | [1] | STAY | KOBSTAY |
| 56-2. | 2432T4113D2 | [1] | CLAMP | KOB |
| 56-3. | ZS18C08040 | [2] | SCREW,Hex, M8 x 40mm | KOBM08x1.25x40mm |
| 56-4. | ZW26X08000 | [2] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 57. | YN21C01395P1 | [2] | WASHER | KOBID 23 x OD 38 x Th 2.0mm |
| 58. | YN21C01396P1 | [2] | WASHER | KOBID 13 x OD 22 x Th 4.5mm |
| 59. | YN21C01681P1 | [1] | BUSHING | KOB |
| 61. | HY35X13025G1 | [1] | WASHER | KOB(M13) |
| 62. | YM21C01034P1 | [1] | GUARD | KOB |
| 63. | ZS18C12025 | [6] | SCREW,Hex, M12 x 25mm | KOBM12x1.75x25mm |
| 64. | YM21C01036P1 | [1] | STAY | KOBSTAY |
| 65. | YN21C01720D1 | [1] | SPACER | KOB |
| 66. | YN21C01720D2 | [1] | SPACER | KOB |
| 67. | YM21C01037P1 | [1] | COVER ASSY | |
| 68. | YN21C01174D1 | [6] | SPACER | KOB100x40x1.6mm |
| 69. | YN21C01174D2 | [6] | SPACER | KOB100x40x2.3mm |
| 70. | YM21C01049P1 | [1] | GUARD | KOB |
| 71. | YM21C01050P1 | [1] | GUARD | KOB |
| 72. | ZM32C10025 | [4] | BOLT | KOBM10x1.50x25mm (Incls. Washer & Lockwasher) |
| 73. | YM21C01051P1 | [1] | COVER | KOBASSY |
