凯斯零件查询(FLX3330B) - FLOATER (12/99-9/02) (01-002) - LEFT DASH ASSEMBLY (FLX3300B CASE ENGINE) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
399 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN316978
|
[1] |
DASH PANEL
|
BN
Left
|
| 2. |
BN314887
|
[1] |
DECAL
|
BN
Left Dash
|
| 3. |
BN304524
|
[1] |
SPEEDOMETER
|
BN
Speedo,3.38 X 80MPH W/OD
|
| 4. |
86636599
|
[1] |
TACHOMETER
|
PA
3.38 x 3K With Hourmeter
|
| 5. |
BN315188
|
[1] |
GAUGE
|
BN
Assembly, Oil Temp Gauge
|
| 6. |
BN2296730
|
[1] |
GAUGE
|
BN
Water Temp "Smart"
|
| 7. |
BN2296752
|
[1] |
FUEL GAUGE
|
BN
|
| 8. |
BN2296753
|
[1] |
GAUGE
|
BN
Voltmeter
|
| 9. |
BN2296754
|
[1] |
OIL PRESSURE GAUGE
|
BN
"Smart"
|
| 10. |
BN2390774
|
[1] |
GAUGE
|
BN
Air Pressure 0-150
|
| 11. |
BN2293217
|
[1] |
BUZZER
|
BN
|
| 12. |
BN2294958
|
[1] |
SWITCH
|
BN
Windshield Wiper Superseded by part number: V91873
|
| 13. |
BN2291956
|
[2] |
SWITCH
|
BN
Cutler Hammer
|
| 14. |
BN2291214
|
[2] |
INDICATOR LIGHT
|
BN
Blue
|
| 15. |
BN2291234
|
[4] |
INDICATOR LIGHT
|
BN
Red
|
| 16. |
BN2394623
|
[1] |
PLUG
|
BN
Dash 1/2" #2643
|
| 17. |
BN2290525
|
[1] |
FITTING
|
BN
VS68AB-4-2
|
| 18. |
BN315370
|
[2] |
INDICATOR LIGHT
|
BN
Amber
|
| . . |
BN314988
|
[1] |
WIRE HARNESS
|
BN
Left Dash, HYD. Lite
|
| . . |
BN314989
|
[1] |
WIRE HARNESS
|
BN
Left Dash, (B2F)
|
| . . |
BN314991
|
[1] |
WIRE HARNESS
|
BN
Lights, (B1F)
|
| . . |
BN314992
|
[1] |
WIRE HARNESS
|
BN
Wiper, (B8F)
|
| . . |
BN314993
|
[1] |
WIRE HARNESS
|
BN
Left Dash, GND
|
| . . |
BN314994
|
[1] |
WIRE HARNESS
|
BN
Left Dash, Lights
|
| . . |
BN314995
|
[1] |
WIRE HARNESS
|
BN
Left Dash, W Lights
|
| . . |
BN315207
|
[1] |
WIRE HARNESS
|
BN
Left Dash, Maintenance
|
