现代零件查询110/130/160DF-7 FORK POSI PIPING(IND, INT, TF, 160DE)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
765 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
34FT-07500
|
[2] |
FORK POSITIONER CYL
|
|
| 1. |
35FT-07500
|
[2] |
FORK POSITIONER CYL
|
|
| 1. |
35FT-07601
|
[2] |
FORK POSITIONER CYLINDER
|
|
| 2. |
34FT-07600
|
[1] |
SIDE SHIFT CYLINDER
|
|
| 2-1. |
XKCD-03345
|
[1] |
SEAL KIT
|
|
| 3. |
P930-064007
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 4. |
P910-064016
|
[1] |
HOSE ASSY-ORFS 0X0
|
|
| 5. |
P930-064014
|
[2] |
HOSE ASSY-ORFS 0X90
|
|
| 6. |
P930-064016
|
[2] |
HOSE ASSY-ORFS 0X90
|
|
| 7. |
34FT-90430
|
[1] |
TUBE
|
|
| 8. |
34FT-90440
|
[1] |
TUBE
|
|
| 9. |
34FT-90450
|
[1] |
PIPE WA
|
|
| 10. |
34FT-90460
|
[1] |
PIPE WA
|
|
| 11. |
31FP-90400
|
[8] |
CLAMP WA
|
|
| 12. |
S015-080506
|
[3] |
BOLT-HEX
|
|
| 13. |
S411-080006
|
[3] |
WASHER-SPRING
|
|
| 14. |
S403-08000B
|
[3] |
WASHER-PLAIN
|
|
| 15. |
34FT-90140
|
[2] |
PIN
|
|
| 16. |
S731-045035
|
[2] |
BUSHING-DU
|
|
| 17. |
S037-102526
|
[2] |
BOLT-W/WASHER
|
|
| 18. |
31FT-90500
|
[4] |
PIN
|
|
| 19. |
S461-630502
|
[4] |
PIN-SPLIT
|
|
| 20. |
P753-160014
|
[1] |
PROTECT COVER-HOSE
|
|
| 21. |
P753-160011
|
[1] |
PROTECT COVER-HOSE
|
|
| 22. |
S552-050203
|
[5] |
CLAMP-BAND
|
|
| 23. |
S015-080306
|
[2] |
BOLT-HEX
|
|
