神钢零件查询(SK160LC) - DYNAMIC ACERA EXCAVATOR 11/2000 ASN YM02U0101 (11/00-12/02) (01-055[02]) - AIR CONDITIONER ASSY, AIR Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
566 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN20M00030F3 | [1] | CONDITIONING UNIT | KOBAIR CONDITIONER INSTALLATION |
| 1. | YN20M01195P1 | [1] | GROMMET | KOB |
| 2. | ZM22C08025 | [6] | BOLT | KOBM08x1.25x25mm (Incls. Washer & Lockwasher) |
| 3. | YT20M01042P1 | [4] | CATCH | KOB |
| 6. | ZC16X03300 | [1] | FASTENER | KOBClamp, Hose -- Min 26 x Max 39mm |
| 7. | ZS32T45010 | [3] | SCREW | KOBM4.5x10mm Self-Taper |
| 8. | ZM22C08020 | [11] | BOLT | KOBM08x1.25x20mm (Incls. Washer & Lockwasher) |
| 9. | YT20M01081P1 | [1] | INSULATOR | KOBINSULATION |
| 10. | 2420R584 | [2] | FASTENER | KOB |
| 11. | YN20M01269P4 | [1] | U-BRACKET | KOB |
| 13. | ZM66C06016 | [1] | BOLT | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) |
| 14. | YN20M01270P1 | [1] | DUCT | KOB |
| 17. | YN20M01258P1 | [1] | DUCT | KOB |
| 18. | YN20M01293F1 | [1] | DUCT | KOBASSY |
| 19. | YN20M01295F1 | [1] | DUCT | KOBASSY |
| 20. | PY01P01043D3 | [1] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 21. | YN20M01248P1 | [1] | SUPPORT | KOB |
| 22. | YN20M01274P1 | [1] | SUPPORT | KOB |
| 23. | YN20M01275P1 | [1] | SUPPORT | KOB |
| 24. | YN20M01271P1 | [1] | RUBBER | KOB |
| 25. | 2418T12346 | [1] | WASHER | KOBID 11 x OD 30 x Th 3.2mm |
| 26. | YN02C01876D1 | [3] | SCREW | KOBM05x12mm Self-Taper |
| 27. | YN02C01877D1 | [4] | SCREW | KOBM03x16mm Self-Taper |
| 29. | YN20M01335P1 | [2] | RUBBER | KOB |
| 30. | YN20M01294F2 | [1] | DUCT | KOBASSY Superseded by part number: YN20M01431F1 |
| 30-1. | YN20M01294S001 | [1] | DUCT | KOB Superseded by part number: YN20M01294F1 |
| 30-2. | YN20M01294S002 | [1] | SEAL | KOB Superseded by part number: YN20M01431F1 |
| 30-3. | YN20M01294S003 | [1] | INSULATION | |
| 31. | YN20M01334F1 | [1] | DUCT | KOBASSY |
| 32. | YN20M01213F2 | [1] | COVER ASSY | KOB |
| 32-2. | YN20M01055P1 | [2] | GRILLE | KOB |
| 32-3. | YT20M01040P1 | [4] | BOLT | KOB |
| 32-4. | YN17M01033D1 | [4] | SCREW | KOBM05x25mm |
| 32-5. | ZW16P05000 | [4] | WASHER | KOBID 05 x OD 10 x Th 1.0mm |
| 32-6. | ZW26X05000 | [4] | LOCK WASHER | KOBLock -- ID 05 x OD 09 x Th 1.3mm |
| 32-7. | ZN18C05004 | [4] | NUT | KOBM05x0.8mm |
| 32-8. | YT20M01041P1 | [4] | GROMMET | KOB |
| 32-9. | YN20M01284F2 | [1] | COVER ASSY | KOBASSY |
| 32-9a. | YN20M01286P1 | [1] | COVER | KOB |
| 32-9b. | YN20M01296F1 | [1] | COVER | KOBASSY |
| 32-9b1. | YN20M01287P1 | [1] | COVER | KOB |
| 32-9b2. | YN20M01296S002 | [2] | PLATE | KOBCATCH Superseded by part number: YN20M01421P1 |
| 32-9b3. | YN20M01296S003 | [4] | SCREW | KOBTAPPING |
| 32-9c. | YN20M01288P1 | [1] | PLATE | KOB |
| 32-9d. | YN20M01284S004 | [1] | ROD | KOB |
| 32-9f. | YN20M01130P1 | [2] | LOCK | KOB |
| 32-9g. | YT20M01035S012 | [4] | SCREW | KOBMACHINE Superseded by part number: ZS32T50010 |
