凯斯零件查询(FLX3330B) - FLOATER (12/99-9/02) (01-010) - CONDENSOR GROUP (FLX3300B CAT ENGINE) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
723 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
276-14712
|
[4] |
SELF-TAP SCREW,Hex Hd, 1/4" x 3/4"
|
CAS
Superseded by part number: 87343649
|
| 2. |
BN304419
|
[4] |
NUT
|
BN
M10-1.5, NLN, 10.9 Superseded by part number: 100037
|
| 3. |
BN300389
|
[4] |
BOLT
|
BN
Hex, M12 x 35, 8.8, Full Thd
|
| 4. |
BN300490
|
[8] |
BOLT
|
BN
M10, FW, 8.8 Superseded by part number: 86625252
|
| 5. |
BN315243
|
[1] |
A/C Condensor, CS
|
|
| 6. |
BN315244
|
[1] |
A/C Condensor, RS
|
|
| 7. |
BN67785
|
[1] |
CONDENSER
|
BN
Coil
|
