| . . | YN13E00034F1 | [1] | HARNESS | KOBHARNESS ASSY, UPPER (FLOOR PLATE) |
| A1. | YN13E01167P2 | [1] | HARNESS | KOB(UNDER CAB FLOOR) |
| A2. | YN13E01156P1 | [1] | HARNESS | KOB(INST PANEL-R) |
| A3. | YN13E01166P2 | [1] | HARNESS | KOB(INST PANEL-L) |
| A4. | ZW26X08000 | [1] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| A5. | ZW16X08000 | [1] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| A6. | ZN18C08007 | [1] | NUT | KOBM08x1.25mm |
| A7. | YN03E01001D5 | [8] | CLIP | KOB195mm Long (7-43/64 in) -- Black |
| A8. | YN13E01190P1 | [1] | GROMMET | KOB |
| A9. | PY01P01043D3 | [2] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| A10. | LE13E01005P1 | [1] | CABLE,100mm L | KOB100mm Long (3-15/16 in) |
| A11. | YN13E01196P1 | [2] | GROMMET | KOB |
| . . | LB14E00003F1 | [1] | HARNESS | KOBASSY, CAB |
| B1. | LB14E01004P1 | [1] | HARNESS | KOB |
| B2. | YN03E01001D5 | [6] | CLIP | KOB195mm Long (7-43/64 in) -- Black |
| B3. | ZS18C06016 | [1] | SCREW,Hex, M6 x 16mm | KOBM06x1.0x16mm |
| B4. | 2432R233D2 | [1] | CLIP | KOB37x12x40mm |
| B5. | ZW26X06000 | [1] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| B6. | ZW16X06000 | [1] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| . . | YM13E00001F1 | [1] | HARNESS ASSY, UPPER | |
| C1. | YM13E01002P3 | [1] | WIRE HARNESS | KOB |
| C2. | YM13EU1002D1 | [1] | NEG BATTERY CABLE | KOB |
| C3. | YN13E01097P1 | [1] | CABLE | KOB400mm Long (15-3/4 in), BATTERY RELAY |
| C4. | 2486R87D1 | [1] | CABLE | KOB |
| C5. | YN13E01098P1 | [1] | CABLE | KOB3400mm Long (133-55/64 in) Starter |
| C6. | LE13E01005P1 | [1] | CABLE,100mm L | KOB100mm Long (3-15/16 in) |
| C7. | ZW26X08000 | [5] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| C8. | ZN18C08007 | [4] | NUT | KOBM08x1.25mm |
| C9. | ZS18C08016 | [1] | SCREW,Hex, M8 x 16mm | KOBM08x1.25x16mm |
| C10. | LC13E01002D1 | [1] | GROMMET | KOB |
| C11. | PY01P01043D3 | [6] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| C12. | ZS18C10020 | [1] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm |
| C13. | 2420Z1330 | [1] | GROMMET | KOB |
| C14. | 2427Z1594D006 | [1] | TRIM PANEL | KOB |
| C15. | ZW16X08000 | [1] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| C16. | 2432R233D3 | [2] | CLIP | KOB50x16x60mm |
| C17. | ZM61C06012 | [2] | BOLT | KOBM06x1.0x12mm (Incls. Washer & Lockwasher) |
| C18. | 2420R372D19 | [2] | GROMMET | KOB |
| C19. | YN03E01001D5 | [3] | CLIP | KOB195mm Long (7-43/64 in) -- Black |
| C20. | ZW16H10000 | [1] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| C21. | 2432R233D1 | [2] | CLIP | KOB37x12x40mm |
| . . | YM16E00002F1 | [1] | HARNESS ASSY, ENGINE | |
| D1. | YM16E01001P2 | [1] | WIRE HARNESS | KOB |
| D2. | YN16E01014P1 | [1] | BRACKET | KOB |
| D3. | 2432R233D1 | [2] | CLIP | KOB37x12x40mm |
| D4. | PY01P01043D3 | [3] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| D5. | 2432R233D3 | [7] | CLIP | KOB50x16x60mm |
| D6. | ZN18C10008 | [1] | NUT | KOBM10x1.50mm |
| D7. | ZW26X10000 | [1] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| D8. | ZM22C08025 | [2] | BOLT | KOBM08x1.25x25mm (Incls. Washer & Lockwasher) |
| D9. | ZM11C08016 | [1] | BOLT | KOBM08x1.25x16mm (Incls. Lockwasher) |
| D10. | ZS18C06045 | [1] | CAP,Hex, M6 x 45mm | KOBScrew -- M06x1.0x45mm |
| D11. | ZW26X06000 | [2] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| D12. | ZW16X10000 | [2] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| D13. | ZW26X08000 | [1] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| D14. | YM16E01006P1 | [1] | PLATE | |
| D15. | ZM22C10020 | [1] | BOLT | KOBM10x1.50x20mm (Incls. Washer & Lockwasher) |
| D16. | ZS18C08016 | [1] | SCREW,Hex, M8 x 16mm | KOBM08x1.25x16mm |
| D17. | ZS18C06010 | [1] | SCREW,Hex, M6 x 10mm | KOBM06x1.0x10mm |
| D18. | ZW16X06000 | [2] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| . . | YM15E00001F1 | [1] | WIRE HARNESS | KOB |
| E1. | YM15E01001P1 | [1] | WIRE HARNESS | KOB |
| E2. | PY01P01043D7 | [1] | CABLE TIE,4.80mm W x 445mm L | KOBWire Ties -- 445mm Long |
