| 1. |
87266355
|
[1] |
FORK
|
TYR
Steering
|
| 2. |
BN324651
|
[1] |
COVER ASSY
|
BN
Axle RS
|
| 3. |
BN324650
|
[1] |
COVER ASSY
|
BN
Axle CS
|
| 4. |
86980378
|
[8] |
BOLT,Hex, M8 x 1.25 x 16mm, Cl 8.8, Full Thd
|
BN
|
| 5. |
86624184
|
[8] |
WASHER,9mm ID x 16mm OD x 1.6mm Thk
|
FOR
|
| 6. |
BN323425
|
[1] |
OIL SEAL
|
BN
Oil, 7.75 X 10 X 0.75
|
| 7. |
90-7762T1
|
[2] |
TAPERED BEARING
|
L
Cone, JM736149
|
| 8. |
90-7761T1
|
[2] |
BEARING CUP
|
L
JM736110 Superseded by part number: 47941924
|
| 9. |
87268058
|
[1] |
BEARING LOCK NUT
|
BN
Fork Bearing Superseded by part number: 84414096
|
| 10. |
87393917
|
[1] |
ARM
|
BN
Steering, Start Serial: 20477 Superseded by part number: 87603098
|
| 10. |
87603098
|
[1] |
ARM
|
BN
Steering
|
| 11. |
BN324111
|
[3] |
BUSHING
|
BN
1.38 X 1.5 X .81
|
| 12. |
87033152
|
[1] |
O-RING,5.85" ID x 6.4" OD x 0.275"
|
BN
#436, CL 6, NBR
|
| 13. |
238-6448
|
[2] |
O-RING,0.275" Thk x 9.475" ID, -448, Cl 6, 90 Duro
|
CAS
|
| 14. |
303401A1
|
[1] |
PLUG
|
CAS
20 mm hole with center pull tab, Serial Range: -20477
|
| 15. |
87344210
|
[1] |
NUT
|
BN
Hex, M12 CL10.9
|
| 16. |
87342144
|
[1] |
BOLT,Hex, M12 x 50mm, Cl 8.8
|
BN
M12 X 50, Full, 8.8
|
| 17. |
87394757
|
[3] |
BOLT,Hex, M20 x 70mm, Cl 10.9
|
BN
Hex, M20 x 70 CL10.9 Full Thrd, Start Serial: 20477
|
| 17. |
86980460
|
[3] |
BOLT,Hex, M20 x 60mm, Cl 8.8
|
BN
M20-2.5 X 60, HH, 8.8 DOR
|
| 18. |
86639847
|
[7] |
WASHER,21.8mm ID x 44.5mm OD x 5mm Thk
|
RAC
|
| 19. |
87342001
|
[3] |
BOLT,Hex, M20 x 90, Class 10.9, DOR
|
BN
, Start Serial: 20477
|
| 19. |
87341550
|
[3] |
BOLT,Hex, M20 - 2.5 x 80mm, Class 8.8, DOR
|
BN
M20 x 80, 8.8
|
| 20. |
331-37
|
[1] |
SPARE PART
|
BN
FLUID, 1 lb. Lithium #2 grease
|
| 21. |
BN55077
|
[1] |
ANTISEIZE
|
BN
Compound-Anti Seize, 0.2
|
| 22. |
BN2293227
|
[1] |
BREATHER
|
BN
301370 1/8" NPT Superseded by part number: 46566
|
| 23. |
BN10151
|
[1] |
LUBE NIPPLE
|
BN
1/8"-27 Straight
|
| 26. |
87392705
|
[1] |
RING
|
BN
Retainer, Start Serial: 20477
|
| 27. |
86980457
|
[1] |
BOLT,Hex, M20 x 40mm, Cl 8.8
|
BN
M20 2.5 X 40, HH, 8.8, DOR
|
| 28. |
87392700
|
[6] |
LOCK WASHER
|
BN
Retainer
|
| 29. |
87392699
|
[1] |
STIFFENER
|
BN
Plate, 12.7 mm
|
