凯斯零件查询(FLX3510) - FLOATER (8/04-8/06) (04-015) - STORAGE GROUP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
557 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87521694
|
[1] |
STORAGE, GASKET SEAL, SEE FIG. 04-016
|
|
| 2. |
BN306290
|
[2] |
HINGE
|
BN
NYLON, TYPE A, M6
|
| 3. |
BN306286
|
[2] |
HINGE
|
BN
NYLON, TYPE B, M6
|
| 4. |
87343625
|
[16] |
HEX SOC SCREW,M6 x 16mm, Cl 8.8, Full Thd
|
BN
M6 X 16 H-SOC 8.8
|
| 5. |
87529312
|
[4] |
WASHER,11mm ID x 24mm OD x 3mm Thk
|
BN
|
| 6. |
86980401
|
[4] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd
|
BN
|
| 7. |
87268752
|
[1] |
DOOR
|
BN
Toolbox, Front
|
| 8. |
87268753
|
[1] |
DOOR
|
BN
Toolbox, Rear
|
| 9. |
F64526
|
[2] |
CABLE
|
CAS
Door
|
| 10. |
86980378
|
[4] |
BOLT,Hex, M8 x 1.25 x 16mm, Cl 8.8, Full Thd
|
BN
|
| 11. |
86980514
|
[4] |
LOCK NUT,Hex, M8, Cl 8, DOR
|
BN
|
| 12. |
343310A1
|
[1] |
BUMPER
|
BN
vibration CSS
|
| 13. |
BN315824
|
[1] |
LOCK NUT
|
BN
5/16-24, NLN, G8
|
| 14. |
BN323944
|
[2] |
LATCH
|
BN
|
| 15. |
BN311631
|
[8] |
BOLT,#10 - 24 x 3/4", SST
|
BN
10-24 x .75, BSH, Stainless Steel
|
| 16. |
BN310266
|
[8] |
BHD LOCK NUT,#10-24, Nylon, Stainless Steel
|
BN
|
