凯斯零件查询(FLX3510) - FLOATER (8/04-8/06) (04-028) - LADDER, FRONT ACCESS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
707 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
344273A1
|
[1] |
SUPPORT
|
BN
Ladder Rail
|
| 2. |
344274A1
|
[1] |
SUPPORT
|
BN
Ladder Rail
|
| 3. |
87270245
|
[3] |
STEP
|
CAS
Black Aluminum
|
| 4. |
344272A1
|
[1] |
BRACKET, SUPPORTING
|
BN
Mount, Ladder
|
| 5. |
344277A1
|
[1] |
SUPPORT
|
BN
Brace, Ladder, Inner
|
| 6. |
344278A1
|
[1] |
SUPPORT
|
BN
Brace, Ladder, Outer
|
| 7. |
BN50146
|
[42] |
WASHER,3/8", Stainless
|
BN
|
| 8. |
43140
|
[12] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 9. |
100037
|
[20] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 10. |
11106231
|
[10] |
BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9
|
LEC
|
