神钢零件查询(SK160LC-6E) - DYNAMIC ACERA EXCAVATOR 08/2004 ASN YM03U0523 (8/04-12/07) (03-017[02]) - HYD LINES, BOOM (SAFETY) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
366 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YB42H01187P1 | [1] | RIGID TUBE | KOB |
| 2. | YB42H01187P1 | [1] | RIGID TUBE | KOB |
| 3. | ZX25M06094 | [2] | HOSE | KOB Superseded by part number: ZX25M06095 |
| 4. | HX20L04090DX | [1] | | |
| 5. | YB28V00011F1 | [2] | SAFETY VALVE | KOB |
| 6. | HG23F04004G1 | [2] | HYD CONNECTOR | KOB |
| 7. | ZH22X06000 | [2] | HYD CONNECTOR | KOB |
| 8. | ZH32X06000 | [2] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOB |
| 9. | HH35X06006G3 | [2] | ELBOW | KOB |
| 10. | 2444Z3155 | [2] | 90 ELBOW,PF 3/8" Fem x PF 3/8" Male | KOB Superseded by part number: YT42H01128P1 |
| 11. | HH55Q06006G1 | [2] | TEE | KOB |
| 12. | ZD12P02600 | [4] | O-RING | KOB |
| 13. | YY42H01330P1 | [2] | O-RING,0.07" Thk x 0.301" ID, -11, Cl 5, 75 Duro | KOB |
| 14. | ZS28C10035 | [8] | SCREW,Hex Socket Head, M10 x 35mm | KOB |
| 15. | ZS28C10070 | [8] | SCREW,Hex Socket Head, M10 x 70mm | KOB |
| 16. | ZE13X12000 | [4] | CLAMP | KOB |
| 17. | ZD12A01600 | [2] | O-RING | KOB |
| 18. | PY01P01043D8 | [4] | CABLE TIE,102mm L | KOB |
