神钢零件查询(SK160LC-6E) - DYNAMIC ACERA EXCAVATOR 08/2004 ASN YM03U0523 (8/04-12/07) (07-021) - CYLINDER ASSEMBLY, ARM (YM01V00008F3) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
631 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM01V00008F3 | [1] | HYDRAULIC CYLINDER | KOBCYLINDER, ARM |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONTUBE ASSY |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONROD, PISTON |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONCYLINDER HEAD |
| 4. | 2438U999S4 | [1] | BUSHING | KOB |
| 5. | 2438U999S5 | [1] | RING | KOBRING, SNAP |
| 7. | 2438U999S7 | [1] | RING | KOBU-RING |
| 8. | 2438U999S8 | [1] | RING | KOBRING BACK UP |
| 9. | 2438U1135S35 | [1] | RING | KOBRING |
| 10. | ZD12G12000 | [1] | O-RING,3.1mm Thk x 119.4mm ID, 90 Duro | KOB |
| 11. | 2438U1102S12 | [1] | O-RING | KOB |
| 12. | ZS23C16075 | [12] | SCREW,Hex Socket Head, M16 x 75mm | KOB |
| 13. | YM01V00008S013 | [1] | BEARING | KOBBEARING |
| 14. | LQ01V00005S014 | [1] | SEAL | KOB |
| 15. | YM01V00008S015 | [1] | PISTON | KOBPISTON |
| 16. | 2438U675S20 | [1] | RING | KOB |
| 17. | YM01V00008S017 | [2] | RING | KOB |
| 18. | YM01V00008S018 | [2] | SCRAPER RING | KOBRING |
| 19. | 2438U675S28 | [2] | RING | KOB |
| 20. | YM01V00008S020 | [1] | SHIM | KOBNUT |
| 21. | 2438U999S21 | [1] | SET SCREW | KOB |
| 22. | 2436U330S16 | [1] | BALL | KOB |
| 23. | 2438U1948S24 | [1] | BEARING | KOBBEARING |
| 24. | LQ01V00007S025 | [1] | SEAL | KOB |
| 25. | 2438U1104S25 | [2] | STOP | KOB |
| 26. | 2438U1948S27 | [1] | RING | KOBRING |
| 28. | 2438U1102S31 | [4] | SEAL | KOB |
| 29. | YM01V00008S029 | [1] | STRAP | KOB |
| 30. | YM01V00008S030 | [1] | STRAP | KOB |
| 31. | ZS18C10035 | [2] | SCREW,Hex, M10 x 35mm | KOBM10x1.50x35mm |
| 32. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 33. | YM01V01003P1 | [2] | BUSHING | KOBBUSHING |
| 34. | YM01V00008S034 | [1] | RING | KOBRING BUFFER |
| 100. | YM01V00008R100 | [1] | REPAIR KIT | KOBIncl 7, 8, 9, 10, 11, 34 |
| 200. | YM01V00008R200 | [1] | KIT | KOBIncl 16 - 19 |
| 300. | YM01V00008R300 | [1] | REPAIR KIT | KOBIncl 7 - 11, 16 - 19, 34 |
| 600. | YM01V00008R600 | [1] | REPAIR KIT | KOBREPAIR KIT, Incl 3, 4 |
| 700. | YM01V00008R700 | [1] | REPAIR KIT | KOBREPAIR KIT, Incl 33 ,35 |
| 800. | YM01V00008R800 | [1] | REPAIR KIT | KOBROD KIT, Incl 33, 36 |
