神钢零件查询(SK160LC-6E) - DYNAMIC ACERA EXCAVATOR 08/2004 ASN YM03U0523 (8/04-12/07) (07-023) - PUMP ASSY, MAIN HYDR Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
603 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM10V00001F4 | [1] | PUMP | KOB Superseded by part number: YM10V00001F6 |
| 1. | YM10V00002F2 | [1] | HYDRAULIC PUMP | SMPUMP, HYDR (See Figure 07-024) |
| 2. | YM10V01001F2 | [2] | REGULATOR | KOBREGULATOR |
| 3. | YB46W00001F1 | [1] | CASE | KOBASSY, GEAR (Use oring ZD12G09500 at attach point) Superseded by part number: YB46W00001F2 |
| 6. | YB35V00003F1 | [2] | VALVE | KOB |
| 7. | YX10V00004F2 | [1] | PUMP | KOB |
