凯斯零件查询(FLX3510) - FLOATER (8/04-8/06) (07-012) - PRIMARY/SECONDARY AIR TANK GROUP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
268 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
86986852
|
[2] |
TANK
|
BN
240 MM Air
|
| 2. |
BN0281508
|
[3] |
BUSHING
|
BN
1/2 x 1/4 PTR-S
|
| 3. |
86625234
|
[2] |
DRAINCOCK/TAP SUPPLY,1/4" NPTF
|
FAR
Valve, 1/4" Weatherhead
|
| 4. |
120104
|
[6] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 5. |
87015284
|
[12] |
WASHER,8.8mm ID x 21.5mm OD x 2.5mm Thk
|
WIC
|
| 6. |
86528579
|
[6] |
NUT,M8 x 1.25
|
WIN
|
| 7. |
444704
|
[1] |
PLUG,Hex Soc, 1/2"-14
|
CAS
Superseded by part number: 87034671
|
| 8. |
76352
|
[2] |
90 ELBOW,3/4" - 16 JIC x 1/2" - 14 NPTF
|
PA
|
| 9. |
BN2290291
|
[1] |
BUSHING
|
BN
0102-4-2
|
| 10. |
87266928
|
[1] |
PRESSURE SWITCH
|
BN
60 psi N/O
|
