凯斯零件查询(FLX3510) - FLOATER (8/04-8/06) (02-009) - FUEL TANK GROUP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
608 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87269155
|
[1] |
TANK
|
TYR
Assembly, 150 Gallon Fuel With Parts
|
| 2. |
87269750
|
[1] |
BRACKET, SUPPORTING
|
BN
Mount, Fuel Tank Vent
|
| 3. |
86999949
|
[1] |
FUEL FILTER
|
GI
Fuel Tank Vent
|
| 4. |
86624184
|
[2] |
WASHER,9mm ID x 16mm OD x 1.6mm Thk
|
FOR
|
| 5. |
43127
|
[1] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 6. |
86528579
|
[1] |
NUT,M8 x 1.25
|
WIN
|
| 7. |
87269744
|
[1] |
FUEL HOSE
|
BN
Fuel, 1/4" id, Bulk Superseded by part number: 47836150
|
| 8. |
86637701
|
[2] |
HOSE CLAMP,12.45mm - 12.95mm
|
FAR
|
| 9. |
84176270
|
[1] |
SENSOR
|
BN
fuel tank level, Start Year: 01-JUN-09
|
| 9. |
86986554
|
[1] |
SENSOR
|
BN
Fuel Tank Level, Years: -01-JUN-09 Superseded by part number: 84176270
|
| . . |
87268404
|
[1] |
GASKET,2.4mm Thk
|
BN
Fuel Sensor
|
| 12. |
87529240
|
[3] |
WASHER,0.53" ID x 1.06" OD x 0.13" Thk
|
BN
0.531 x 1.062 x 0.134 HTS DOR HDN
|
| 13. |
BN300407
|
[3] |
FLANGE NUT
|
BN
Flg, 1/2"-13, G8
|
| 14. |
BN2395008-002
|
[3] |
STRAP
|
TYR
Assembly, Fuel Tank
|
| 15. |
BN2395003-005
|
[3] |
NUT
|
BN
Fuel Tank Strap Superseded by part number: 87343935, 87310599
|
| 16. |
87270794
|
[5] |
BOLT,Hex, M5 x 30mm, SST
|
BN
M5 x 30, SS
|
