神钢零件查询(SK160LC-6E) - DYNAMIC ACERA EXCAVATOR 08/2004 ASN YM03U0523 (8/04-12/07) (09-032 ) - EXHAUST MANIFOLD Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
416 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 11961. | VAME080482 | [1] | INSULATOR, ENG AIR INTAKE PIPE HEAT,0203.1 - | |
| 11999. | VAMH000392 | [4] | BOLT | KOBENG AIR MAKE LINE,0203.1 -,MASHER ASSEMBLE D.8X12 |
| 12000. | VAME080450 | [1] | EXHAUST MANIFOLD | KOB0203.1 - |
| 12010. | VAME014349 | [4] | GASKET | KOBEXHAUST MANIFOLD,0203.1 - |
| 12089. | VAMF407726 | [4] | STUD | KOBEXHAUST MANIFOLD,0203.1 -,10X25 |
| 12094B. | VAME210059 | [8] | SPACER | KOBEXHAUST MANIFOLD,0203.1 -,T = 21 |
| 12096. | VAMH004054 | [8] | NUT | KOBEXHAUST MANIFOLD,0203.1 -,SELF LOCKING,FL ANGE.10 Superseded by part number: 134868A1 |
