凯斯零件查询(FLX3510) - FLOATER (8/04-8/06) (02-026) - A/C COMPRESSOR GROUP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
864 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87269582
|
[1] |
BRACKET
|
BN
A/C Compressor
|
| 2. |
86993462
|
[1] |
AIRCOND. COMPRESSOR
|
GI
12V Double Groove Superseded by part number: 47773024
|
| 2. |
86993462GV
|
[1] |
AIRCOND. COMPRESSOR
|
MKT
Value Superseded by part number: 86993462
|
| . . |
86993462R
|
[1] |
REMAN-COMPRESSOR
|
MKT
FLX3010, FLX3510 both (8/04-8/06)
|
| . . |
86993462C
|
[1] |
CORE-COMPRESSOR
|
MKT
Return Number
|
| . . |
48017123R
|
[1] |
REMAN-A/C COMP KIT
|
RAC
Reman Kit -- A/C Compressor, Receiver-Dryer, Valve
|
| . . |
48017123C
|
[1] |
REMAN-A/C COMP KIT
|
RAC
Return Number
|
| 3. |
84716C1
|
[1] |
SUPPORT
|
IH
Strap, Adjusting Compressor Superseded by part number: 87306665
|
| 4. |
892-11010
|
[4] |
LOCK WASHER,M10
|
CAS
Superseded by part number: 140028
|
| 5. |
86625253
|
[2] |
WASHER,11mm ID x 24mm OD x 2mm Thk
|
FAR
|
| 6. |
86508575
|
[2] |
BOLT,Hex, M10 x 130mm, Cl 8.8
|
NH
|
| 7. |
120112
|
[1] |
BOLT,Hex, M10 x 1.5 x 40mm, Cl 8.8, Full Thd
|
NH
|
| 8. |
905-10025
|
[5] |
BOLT,Hex Flg, M10 x 25mm
|
CAS
Superseded by part number: 274251
|
| 9. |
100037
|
[2] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 10. |
J919624
|
[1] |
PULLEY
|
CAS
Compressor Drive, Years: -01-SEP-09 Superseded by part number: 84167711
|
| 11. |
A184652
|
[1] |
V-BELT,12.70 mm W x 1017.00 mm L
|
CAS
Compressor Drive
|
| 10. |
84167711
|
[1] |
PULLEY,179.56mm OD
|
BN
Compressor Drive, Start Year: 01-SEP-09
|
| 12. |
3120737R1
|
[2] |
WASHER,10.8mm ID x 25mm OD x 5mm Thk
|
IH
10.8 x 25 x 5 mm
|
| 13. |
BN1243001
|
[1] |
LOCTITE
|
BN
243-31 Removable
|
