神钢零件查询(SK160LC-6E) - DYNAMIC ACERA EXCAVATOR 08/2004 ASN YM03U0523 (8/04-12/07) (00-002) - TUBE SLEEVES Kobelco

Pos.	Part No	Qty	Parts name	Comments
. .	ZF93S06000	[1]	FERRULE	KOBSLEEVE, TYPE: IHARA, TUBR DIA:Ød: 6 Superseded by part number: ZF96N06000, ZF96S06000
. .	ZF93S08000	[1]	FERRULE	KOBSLEEVE, TYPE: IHARA, TUBR DIA:Ød: 8 Superseded by part number: ZF96S08000, ZF96N08000
. .	ZF93S10000	[1]	FERRULE	KOBSLEEVE, TYPE: IHARA, TUBR DIA:Ød: 10 Superseded by part number: ZF96S10000, ZF96N10000
. .	ZF93S12000	[1]	FERRULE	KOBSLEEVE, TYPE: IHARA, TUBR DIA:Ød: 12 Superseded by part number: ZF96N12000, ZF96S12000
. .	ZF93S15000	[1]	FERRULE	KOBSLEEVE, TYPE: IHARA, TUBR DIA:Ød: 15
. .	ZF93S18000	[1]	FERRULE	KOBSLEEVE, TYPE: IHARA, TUBR DIA:Ød: 18
. .	ZF93S22000	[1]	FERRULE	KOBSLEEVE, TYPE: IHARA, TUBR DIA:Ød: 22
. .	ZF93S28000	[1]	FERRULE	KOBSLEEVE, TYPE: IHARA, TUBR DIA:Ød: 28 Superseded by part number: ZA93S28000
. .	ZF93S32000	[1]	FERRULE	KOBSLEEVE, TYPE: IHARA, TUBR DIA:Ød: 32
. .	ZF93S35000	[1]	FERRULE	KOBSLEEVE, TYPE: IHARA, TUBR DIA:Ød: 35
. .	ZF93S38000	[1]	FERRULE	KOBSLEEVE, TYPE: IHARA, TUBR DIA:Ød: 38
. .	NSS	[1]	NOT SOLD SEPARAT	CONSLEEVE, TYPE: NIPPON A.M.C, TUBR DIA:Ød: 6
. .	ZA93S10000	[1]	TUBE NUT	KOBSLEEVE, TYPE: NIPPON A.M.C, TUBR DIA:Ød: 10
. .	ZA93S15000	[1]	FERRULE	KOBSLEEVE, TYPE: NIPPON A.M.C, TUBR DIA:Ød: 15
. .	ZA93S18000	[1]	FERRULE	KOBSLEEVE, TYPE: NIPPON A.M.C, TUBR DIA:Ød: 18
. .	ZA93S22000	[1]	RING	KOBSLEEVE, TYPE: NIPPON A.M.C, TUBR DIA:Ød: 22
. .	ZA93S28000	[1]	FERRULE	KOBSLEEVE, TYPE: NIPPON A.M.C, TUBR DIA:Ød: 28
. .	ZA93S35000	[1]	FERRULE	KOBSLEEVE, TYPE: NIPPON A.M.C, TUBR DIA:Ød: 35
