| 1. | ZE13Q08000 | [1] | FLANGE | KOB4-BOLT FLANGE CAPS, (NOM. SIZE): 12.7(1/2"), DIM A: 18.24 (.72"), DIM B: 40.49 (1.59") |
| 1. | ZE13Q12000 | [1] | PLUG | KOB4-BOLT FLANGE CAPS, (NOM. SIZE): 19.1(3/4"), DIM A: 23.80 (.94"), DIM B: 50.80 (2.00") |
| 1. | ZE13Q16000 | [1] | PLUG | KOB4-BOLT FLANGE CAPS, (NOM. SIZE): 25.4(1.0"), DIM A: 27.76 (1.09"), DIM B: 57.15 (2.25") |
| 1. | ZE13Q20000 | [1] | PLUG | KOB4-BOLT FLANGE CAPS, (NOM. SIZE): 31.8(1.25"), DIM A: 31.75 (1.25"), DIM B: 66.68 (2.62") |
| 1. | ZE13Q24000 | [1] | FLANGE | KOB4-BOLT FLANGE CAPS, (NOM. SIZE): 38.1(1.50"), DIM A: 36.50 (1.44"), DIM B: 79.38 (3.12") |
| 1. | ZE13Q32000 | [1] | FLANGE | KOB4-BOLT FLANGE CAPS, (NOM. SIZE): 50.8(2.0"), DIM A: 44.45 (1.75"), DIM B: 96.82 (3.81") |
| 2. | 2445Z831D1 | [1] | O-RING | KOB4-BOLT FLANGE CAPS, (NOM. SIZE): 12.7(1/2"), DIM A: 18.24 (.72"), DIM B: 40.49 (1.59") |
| 2. | ZD12P02600 | [1] | O-RING | KOB4-BOLT FLANGE CAPS, (NOM. SIZE): 19.1(3/4"), DIM A: 23.80 (.94"), DIM B: 50.80 (2.00") |
| 2. | ZD12P03400 | [1] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOB4-BOLT FLANGE CAPS, (NOM. SIZE): 25.4(1.0"), DIM A: 27.76 (1.09"), DIM B: 57.15 (2.25") |
| 2. | ZD12P03800 | [1] | O-RING | KOB4-BOLT FLANGE CAPS, (NOM. SIZE): 31.8(1.25"), DIM A: 31.75 (1.25"), DIM B: 66.68 (2.62") |
| 2. | ZD12P04800 | [1] | O-RING,3.5mm Thk x 47.7mm ID | KOB4-BOLT FLANGE CAPS, (NOM. SIZE): 38.1(1.50"), DIM A: 36.50 (1.44"), DIM B: 79.38 (3.12") |
| 2. | 2445Z831D2 | [1] | O-RING | KOB4-BOLT FLANGE CAPS, (NOM. SIZE): 50.8(2.0"), DIM A: 44.45 (1.75"), DIM B: 96.82 (3.81") |
| 3. | ZS18C08030 | [1] | SCREW,Hex, M8 x 30mm | KOB4-BOLT FLANGE CAPSCREWS, (NOM. SIZE): 12.7(1/2"), DIM A: 18.24 (.72"), DIM B: 40.49 (1.59") |
| 3. | ZS18C10035 | [1] | SCREW,Hex, M10 x 35mm | KOB4-BOLT FLANGE CAPS, (NOM. SIZE): 19.1(3/4"), DIM A: 23.80 (.94"), DIM B: 50.80 (2.00") |
| 3. | ZS18C12040 | [1] | SCREW,Hex, M12 x 40mm | KOB4-BOLT FLANGE CAPS, (NOM. SIZE): 25.4(1.0"), DIM A: 27.76 (1.09"), DIM B: 57.15 (2.25") |
| 3. | ZS18C14045 | [1] | CAP,Hex, M14 x 45mm | KOB4-BOLT FLANGE, (NOM. SIZE): 31.8(1.25"), DIM A: 31.75 (1.25"), DIM B: 66.68 (2.62") |
| 3. | ZS18C16050 | [1] | SCREW,Hex, M16 x 50mm | KOB4-BOLT FLANGE, (NOM. SIZE): 38.1(1.50"), DIM A: 36.50 (1.44"), DIM B: 79.38 (3.12") |
| 3. | ZS18C20065 | [1] | SCREW,Hex, M20 x 65mm | KOB4-BOLT FLANGE CAPS, (NOM. SIZE): 50.8(2.0"), DIM A: 44.45 (1.75"), DIM B: 96.82 (3.81") |
| 4. | ZW26X08000 | [1] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm, 4-BOLT FLANGE CAPS, (NOM. SIZE): 12.7(1/2"), DIM A: 18.24 (.72"), DIM B: 40.49 (1.59") Superseded by part number: 83990583 |
| 4. | ZW26X10000 | [1] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm, 4-BOLT FLANGE CAPS, (NOM. SIZE): 19.1(3/4"), DIM A: 23.80 (.94"), DIM B: 50.80 (2.00") |
| 4. | ZW26X12000 | [1] | LOCK WASHER | KOB4-BOLT FLANGE CAPS, (NOM. SIZE): 25.4(1.0"), DIM A: 27.76 (1.09"), DIM B: 57.15 (2.25") |
| 4. | ZW26X14000 | [1] | WASHER | KOB4-BOLT FLANGE CAPS, (NOM. SIZE): 31.8(1.25"), DIM A: 31.75 (1.25"), DIM B: 66.68 (2.62") |
| 4. | ZW26X16000 | [1] | LOCK WASHER | KOB4-BOLT FLANGE CAPS, (NOM. SIZE): 38.1(1.50"), DIM A: 36.50 (1.44"), DIM B: 79.38 (3.12") |
| 4. | ZW26X20000 | [1] | LOCK WASHER | KOB4-BOLT FLANGE CAPS, (NOM. SIZE): 50.8(2.0"), DIM A: 44.45 (1.75"), DIM B: 96.82 (3.81") |
| 5. | ZS23C08030 | [1] | SCREW,Hex Socket Head, M8 x 30mm | KOB4-BOLT FLANGE, (NOM. SIZE): 12.7(1/2"), DIM A: 18.24 (.72"), DIM B: 40.49 (1.59") Superseded by part number: ZS28C08030 |
| 5. | ZS23C10035 | [1] | SCREW,Hex Socket Head, M10 x 35mm | KOB4-BOLT FLANGE CAPS, (NOM. SIZE): 19.1(3/4"), DIM A: 23.80 (.94"), DIM B: 50.80 (2.00") |
| 5. | ZS23C12040 | [1] | SCREW,Hex Socket Head, M12 x 40mm | KOB4-BOLT FLANGE CAPS, (NOM. SIZE): 25.4(1.0"), DIM A: 27.76 (1.09"), DIM B: 57.15 (2.25") |
| 5. | ZS23C14045 | [1] | SCREW,Hex Socket Head, M14 x 45mm | KOB4-BOLT FLANGE CAPS, (NOM. SIZE): 31.8(1.25"), DIM A: 31.75 (1.25"), DIM B: 66.68 (2.62") Superseded by part number: ZS28C14045 |
| 5. | ZS23C16050 | [1] | CAPSCREW,Hex Socket Head, M16 x 50mm | KOBSCREW 4-BOLT FLANGE CAPS, (NOM. SIZE): 38.1(1.50"), DIM A: 36.50 (1.44"), DIM B: 79.38 (3.12") |
| 5. | ZS23C20065 | [1] | SCREW,Hex Socket Head, M20 x 65mm | KOB4-BOLT FLANGE CAPS, (NOM. SIZE): 50.8(2.0"), DIM A: 44.45 (1.75"), DIM B: 96.82 (3.81") |
| 6. | ZW26K08000 | [1] | LOCK WASHER | KOB4-BOLT FLANGE CAPS, (NOM. SIZE): 12.7(1/2"), DIM A: 18.24 (.72"), DIM B: 40.49 (1.59") |
| 6. | ZW26K10000 | [1] | LOCK WASHER | KOB4-BOLT FLANGE CAPS, (NOM. SIZE): 19.1(3/4"), DIM A: 23.80 (.94"), DIM B: 50.80 (2.00") Superseded by part number: 12581679 |
| 6. | ZW26K12000 | [1] | LOCK WASHER | KOB4-BOLT FLANGE CAPS, (NOM. SIZE): 25.4(1.0"), DIM A: 27.76 (1.09"), DIM B: 57.15 (2.25") |
| 6. | ZW26K14000 | [1] | LOCK WASHER | KOB4-BOLT FLANGE CAPS, (NOM. SIZE): 31.8(1.25"), DIM A: 31.75 (1.25"), DIM B: 66.68 (2.62") |
| 6. | ZW26K16000 | [1] | LOCK WASHER | KOB4-BOLT FLANGE CAPS, (NOM. SIZE): 38.1(1.50"), DIM A: 36.50 (1.44"), DIM B: 79.38 (3.12") |
| 6. | ZW26K20000 | [1] | WASHER | KOB4-BOLT FLANGE CAPS, (NOM. SIZE): 50.8(2.0"), DIM A: 44.45 (1.75"), DIM B: 96.82 (3.81") |
