| . . | YM32TU1040F3 | [1] | KIT, FIELD INSTAL | |
| 1. | 24100P1005F1 | [1] | VALVE | KOB Superseded by part number: 24100P1005F3 |
| 2. | 24100P1006F1 | [2] | VALVE | KOB Superseded by part number: 24100P1006F2 |
| 3. | 2414Z199D050 | [2] | PROTECTIVE SLEEVE | KOBHose -- 500mm Long (19-11/16 in) |
| 4. | 2414Z199D100 | [4] | PROTECTIVE SLEEVE | KOBHose -- 1000mm Long (39-3/8 in) |
| 5. | 2416N6141 | [1] | BLOCK | KOB |
| 6. | 2416T9804 | [2] | BLOCK | KOBTapped -- 70x38x16mm |
| 7. | 2416T9804D4 | [2] | BLOCK | KOBTapped -- 70x38x22mm Superseded by part number: YN02F01333P1 |
| 8. | 2418T10357 | [4] | WASHER | KOBID 13 x OD 30 x Th 3.2mm Superseded by part number: 2418T12345 |
| 9. | 2420R349D040 | [1] | HOSE,6.35mm ID x 400mm L | KOB1/4" PF, 400mm Long (15-3/4 in) |
| 11. | 2420R349D270 | [2] | HOSE | KOB2700mm Long (106-19/64 in) |
| 12. | 2420R349D280 | [1] | HOSE | KOBPF 1/4 Superseded by part number: HX21E04280DX |
| 13. | 2420R349D315 | [1] | HOSE | KOB(PF 1/4) 3150mm Long (124 in) |
| 14. | 2420T4404 | [2] | PLUG | KOB1-1/16" - 12 UNC |
| 15. | 2420T4405 | [2] | PLUG | KOB3/4"-16UNF x 22mm Long |
| 16. | 2432T2434 | [1] | CLAMP | KOBDouble Line -- 129x38x15mm (Ø29xØ36mm) |
| 17. | 2432T5924 | [5] | CLAMP | KOBSingle Block -- 80x50x25mm |
| 18. | 2432T6122 | [5] | CLAMP | KOBSingle Block -- 75x50x25mm |
| 19. | 2444P1744D2 | [2] | CONNECTION | KOB(No O-Ring supplied) |
| 20. | 2444R1120D030 | [1] | HOSE | KOB300mm Long (11-13/16 in) |
| 21. | 2444R1120D110 | [1] | HOSE | KOB(1/4" PF) 1100mm Long (43-19/64 in) |
| 22. | 2444R399D6 | [1] | ELBOW | KOB90° -- 1"PFx1-1/4"PFx41.5mm Long (Incls. O-Ring ZD12P03800) |
| 23. | 2444R399D7 | [1] | ELBOW | KOB |
| 24. | 2444T2657D1 | [2] | HYD CONNECTOR | KOBM30x1.5mm - 3/4"-16UNF x 46mm Long |
| 25. | 2444T2958 | [2] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01800) |
| 26. | 2444Z2760 | [1] | HYD CONNECTOR | KOB1" PFx56.5mm Long (Incls. O-Ring ZD12P02900) |
| 27. | 2444Z2894 | [2] | 90 ELBOW | KOBElbow, 90° -- 1/4" PF (Incls. O-Ring ZD12P01100) |
| 28. | 2444Z3722D4 | [1] | HOSE | KOB(1" PF) 800mm Long (31-1/2 in) |
| 29. | 2479U1190F32 | [1] | SWITCH | KOB |
| 30. | EN24S00008P1 | [2] | RELAY | KOB(5 Spade Relay) |
| 31. | HG23H12012G1 | [2] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P02400) |
| 32. | HG23H12016G1 | [1] | HYD CONNECTOR | KOB1 3/16"-12UN-PF1" Superseded by part number: YW03H01227P1 |
| 33. | HG24F10012G3 | [1] | HYD CONNECTOR | KOB1"-14UNS - 3/4"PT x 90mm Long (Incls. O-Ring ZD12P02400) |
| 34. | HG33F10016G1 | [1] | ELBOW | KOB90° -- (Incls. O-Ring ZD12P02900) 56mm Long |
| 35. | HG33H16012G1 | [1] | ELBOW | KOB |
| 36. | HH25R04004G3 | [1] | CONNECTION | KOB1/4"PFx72mm Long (Incls. O-Ring ZD12P01100) |
| 38. | HH35X04004G3 | [1] | 90 ELBOW | KOB90° -- 1/4" PF (Incls. O-Ring ZD12P01100) |
| 39. | HH55Q06006G1 | [2] | TEE | KOB3/8" PF (Incls. O-Ring ZD12P01400) |
| 40. | LB42H01001P1 | [4] | CLAMP | KOB |
| 41. | LB42H01004P1 | [2] | BUSHING,28mm ID x 45mm OD x 68mm L | KOB |
| 42. | LC12B01076P1 | [2] | SUPPORT | KOB |
| 43. | LC35V00004F2 | [1] | SOLENOID VALVE | KOB |
| 44. | LC42H01020P1 | [2] | BUSHING,34mm ID x 53mm OD x 68mm L | KOB |
| 45. | LE03H01234P1 | [1] | CLAMP | KOB |
| 46. | LF03M01004P1 | [2] | BOOT | KOB |
| 47. | LS43H01005P1 | [4] | CLAMP,43mm ID, 12mm Bolt Hole, J Type | KOB |
| 48. | PY01P01043D3 | [6] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 49. | PY20T01062P1 | [1] | CAUTION DECAL | KOBDecal, Caution - Attachment operation by foot pedal. Always check the … |
| 50. | YB03M01003F2 | [1] | GRIP | KOBAssembly |
| 51. | YB03M01003F3 | [1] | GRIP | KOBAssembly |
| 52. | YM03H01015P1 | [1] | TUBE | KOB |
| 53. | YM03H01041P2 | [1] | BRACKET | KOB Superseded by part number: YM03H01065P1 |
| 54. | YM03H01042P1 | [1] | TUBE | KOB |
| 55. | YM03H01043P1 | [1] | SUPPORT | KOB |
| 56. | YM03H01064P1 | [1] | SUPPORT | KOB |
| 57. | YM06H01002D2 | [1] | HOSE | KOB900mm Long (35-7/16 in) |
| 58. | YM12B01041P1 | [1] | LINK | KOB |
| 59. | YM12B01042P1 | [1] | POWER ARM | KOB |
| 60. | YM30H01027P1 | [1] | TUBE | KOB |
| 61. | YM42H01056P1 | [1] | O-RING,29.87mm ID x 33.43mm OD x 1.78mm | KOBID 29.87 ± 0.15 x OD 33.43mm Superseded by part number: YY42H01313P1 |
| 62. | YM42H01105P1 | [1] | TUBE | KOB |
| 63. | YM42H01106P1 | [1] | TUBE,2714, 1252 mm L | KOB |
| 64. | YM42H01117P1 | [1] | TUBE,2353, 166 mm L | KOB |
| 65. | YM42H01118P1 | [1] | TUBE,2353, 166 mm L | KOB |
| 66. | YM42H01156P1 | [1] | TUBE | KOB |
| 67. | YM42H01157P1 | [1] | TUBE | KOB |
| 68. | YM42H01158P1 | [2] | TUBE | KOB |
| 69. | YM43H01040P1 | [1] | TUBE,1209, 84 mm L | KOB |
| 70. | YM43H01041P1 | [1] | TUBE,1209, 84 mm L | KOB |
| 71. | YM43H01054P1 | [1] | TUBE | KOB |
| 72. | YM43H01055P1 | [1] | TUBE | KOB |
| 73. | YM64H01019P1 | [1] | BRACKET | KOB |
| 74. | YM64H01023P1 | [1] | BRACKET | KOB |
| 75. | YN02B01031D2 | [1] | SPACER | KOB |
| 76. | YN03H01489P1 | [1] | BLOCK | KOB |
| 77. | YN03H01653P1 | [1] | TUBE | KOB |
| 78. | YN03H01654P1 | [1] | TUBE | KOB |
| 79. | YN03M01483P1 | [2] | BOOT | KOB |
| 80. | YN10V00024F1 | [1] | HYDRAULIC PUMP,20.3 CC | KOB |
| 81. | YN11E01111P1 | [1] | HARNESS | KOB |
| 83. | YN11E01113D1 | [1] | HARNESS | KOB |
| 84. | YN20M01046DV | [1] | PROTECTIVE SLEEVE,22.10mm ID x 27.00mm OD x 950.00mm | KOBProtective Plastic |
| 85. | YN20T01414P1 | [1] | LABEL | KOBDecal, Caution - Maintenance - (when using nibbler or breaker) … |
| 86. | YN30H01078D3 | [1] | HOSE | KOB |
| 87. | YN30H01115P1 | [1] | FLANGE | KOB(Multi Port Block), No service parts |
| 88. | YN42H01058P1 | [12] | CLAMP | KOB |
| 89. | YN42H01059P1 | [12] | CLAMP | KOB |
| 90. | YN42H01366P1 | [1] | CLAMP | KOB |
| 91. | YN68H01035P1 | [2] | CLAMP | KOB |
| 94. | YT20T01054P1 | [1] | LABEL | KOBDecal, Caution - Do not set this switch to nibbler combined flow operation … |
| 95. | YW43H01044P1 | [2] | BRACKET | KOB |
| 96. | YY20T01039P1 | [1] | LABEL | KOBDecal, Caution, Procedure to change selector valve… |
| 97. | YY30V00008F1 | [1] | VALVE | KOBCONTROL |
| 98. | ZA23B22000 | [2] | HYD CONNECTOR | KOBM30x1.50x38mm Long |
| 99. | ZA23H18008 | [1] | HYD CONNECTOR | KOB |
| 100. | ZA33F18008 | [1] | ELBOW | KOB |
| 101. | ZA33F22008 | [2] | 90 ELBOW,M30 x 1.5 ORB x 1/2" NPT | KOB90° -- 1/2" PF - M30x1.50x34mm Long (Incls. O-Ring ZD12P02400) |
| 102. | ZC26X18011 | [1] | CLAMP | KOB Superseded by part number: ZC26M18011 |
| 103. | ZC26X22011 | [6] | CLAMP | KOBSingle Line -- 38x29x65mm Long |
| 104. | ZD12A01600 | [4] | O-RING | KOBID 15.60 ± 0.12 x OD 19.16mm |
| 105. | ZD12A01800 | [10] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOBID 18.77 ± 0.12 x OD 22.33mm |
| 106. | ZD12A02100 | [4] | O-RING | KOBID 23.52 ± 0.15 x OD 27.08mm |
| 107. | ZD12P01800 | [3] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 108. | ZD12P02400 | [2] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 109. | ZD12P03400 | [1] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOBID 33.70 ± 0.33 x OD 40mm |
| 110. | ZE12X20000 | [2] | CLAMP | KOB |
| 111. | ZE72X04000 | [2] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
| 112. | ZE72X06000 | [2] | PLUG | KOB3/8" PF, (Incls. O-Ring ZD12P01400) |
| 113. | ZE72X16000 | [2] | PLUG | KOB(Incls. O-Ring ZD12P02900) |
| 114. | ZG23F10012 | [1] | HYD CONNECTOR | KOB5/8"-3/4" PT (Incls. O-Ring ZD12P02400) |
| 115. | ZG33F10012 | [1] | 90 ELBOW,1"-14 UNS x PF 3/4" | KOB90° -- 1" -14UNS - PF 3/4 (Incls. O-Ring ZD12P02400) |
| 116. | ZH22X04000 | [3] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| 117. | ZH22X04006 | [2] | HYD CONNECTOR | KOB(Incls. O-Ring 237-6006) |
| 118. | ZH22X06000 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01400) |
| 119. | ZH32X04000 | [7] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| 120. | ZH32X04006 | [3] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 3/8", O-Ring | KOB90° -- 1/4"x3/8"PF (Incls. O-Ring 237-6006 Alternate ZD12P01400) |
| 121. | ZH32X08000 | [2] | 90 ELBOW,Male, 30 Degree Fl, PF 1/2" x PF 1/2", O-Ring | KOBElbow, 90° -- 1/2"PT (Incls. O-Ring ZD12P01800) |
| 123. | ZM61C06016 | [2] | BOLT | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) |
| 124. | ZN18C10008 | [1] | NUT | KOBM10x1.50mm |
| 125. | ZN18C12010 | [1] | NUT | KOBM12x1.75mm |
| 126. | ZS18C08020 | [8] | SCREW,Hex, M8 x 20mm | KOBM08x1.25x20mm |
| 127. | ZS18C08025 | [10] | SCREW,Hex, M8 x 25mm | KOBM08x1.25x25mm |
| 128. | ZS18C08030 | [3] | SCREW,Hex, M8 x 30mm | KOBM08x1.25x30mm |
| 129. | ZS18C08065 | [4] | SCREW,Hex, M8 x 65mm | KOBM08x1.25x65mm |
| 130. | ZS18C10020 | [2] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm |
| 131. | ZS18C10030 | [10] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| 132. | ZS18C10045 | [7] | SCREW,Hex, M10 x 45mm | KOBM10x1.50x45mm |
| 133. | ZS18C10060 | [1] | SCREW,Hex, M10 x 60mm | KOBM10x1.50x60mm |
| 134. | ZS18C12030 | [9] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm |
| 135. | ZS18C12040 | [12] | SCREW,Hex, M12 x 40mm | KOBM12x1.75x40mm |
| 136. | ZS18C12045 | [4] | SCREW,Hex, M12 x 45mm | KOBM12x1.75x45mm |
| 137. | ZS18C12060 | [20] | SCREW,Hex, M12 x 60mm | KOBM12x1.75x60mm |
| 138. | ZS18C12065 | [3] | SCREW,Hex, M12 x 65mm | KOBM12x1.75x65mm |
| 139. | ZS28C10035 | [6] | SCREW,Hex Socket Head, M10 x 35mm | KOBScrew -- M10x1.50x35mm |
| 140. | ZS28C10045 | [4] | SCREW,Hex Socket Head, M10 x 45mm | KOBM10x1.50x45mm |
| 141. | ZW16H08000 | [19] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| 142. | ZW16H10000 | [13] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 143. | ZW16H12000 | [11] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 144. | ZW16X08000 | [7] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 145. | ZW16X10000 | [8] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 146. | ZW26K10000 | [8] | LOCK WASHER | KOBLock -- ID 10 x OD 15.7 x Th 2.5mm Superseded by part number: 12581679 |
| 147. | ZW26X10000 | [8] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 148. | ZW26X12000 | [38] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 149. | ZX20H12105 | [2] | HOSE | KOB1050mm Long (41-21/64 in) |
| 150. | ZX28N10090 | [2] | FLEXIBLE HOSE | KOB |
| 151. | ZX30H10058 | [1] | HOSE | KOB |
| 152. | ZX30H10066 | [1] | HOSE | KOB |
| 153. | ZX32M08110 | [1] | HOSE ASSY. | KOB |
| 154. | ZX50H12185 | [1] | HOSE | KOB1850mm Long (72-53/64 in) |
| 155. | ZX50H16185 | [1] | HOSE | KOB1850mm Long (72-53/64 in) |
| 156. | ZX58N10175 | [2] | HOSE | KOB1750mm Long (68-57/64 in) |
| 157. | YN26M00054P1 | [1] | FLOOR MAT | KOB |
| 158. | HH25X04004G2 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01100) |
| 159. | ZS18C10025 | [2] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 160. | YX52S00010P1 | [1] | SENSOR | KOBPressure (PF 1/4) Superseded by part number: LC52S00019P1 |
| 161. | 2420R349D085 | [1] | HOSE,6.35mm ID x 850mm L | KOB850mm Long (33-29/64 in) |
| 162. | ZN18C08007 | [1] | NUT | KOBM08x1.25mm |
| 163. | PY03M01026P1 | [1] | PIN | KOBM08x1.25x115mm Long |
| 164. | ZS28C10020 | [2] | SCREW,Hex Socket Head, M10 x 20mm | KOBM10x1.50x20mm |
| 165. | YT30M01002F1 | [1] | LOCK | KOBAssembly |
| 166. | YN03M01319P1 | [1] | PEDAL | KOB |
| 167. | YN30V00080F1 | [1] | VALVE | KOB |
| 168. | YN03M01266P2 | [1] | RUBBER SLEEVE | KOB |
| 169. | PY01P01043D6 | [6] | CABLE TIE,4.80mm W x 383mm L | KOBWire Ties -- 368mm Long |
