JR943034
|
[1] |
REMAN-CRANKSHAFT
|
CAS
Assembly, Engine, Remanufactured, Component Parts Shown On This Page Do Not Apply To The Remanufactured Assembly
|
| . . |
JC943034
|
[1] |
CORE-CRANKSHAFT
|
CAS
Return Number - Use This Part Number To Return Crankshaft Core For Credit When Using A Remanufactured Assembly
|
| . . |
J943034
|
[1] |
CRANKSHAFT
|
CAS
Assembly - Engine, New Superseded by part number: J943033, J918776AM, J904483
|
| . . |
J943033R
|
[1] |
REMAN-CRANKSHAFT
|
RAC
FLX3010, FLX3510, Both FLOATER, Assembly - Engine, New (8/04-8/06), Reman for New PN J943034
|
| . . |
J943033C
|
[1] |
CORE-CRANKSHAFT
|
RAC
Return Number
|
| 1. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Crankshaft
|
| 2. |
J918776
|
[1] |
GEAR
|
CAS
Crankshaft Superseded by part number: J918776AM
|
| 3. |
J904483
|
[1] |
PIN,6.01mm OD x 8mm L
|
CAS
Dowel
|
| 5. |
87422144
|
[1] |
PULLEY,199.42mm OD
|
CAS
Crankshaft
|
| 5A. |
J941092
|
[1] |
DAMPER
|
CAS
Vibration Superseded by part number: 87357611
|
| 6. |
J914118
|
[5] |
FLANGE BOLT,Hex, M14 x 1.5 x 60mm, Cl 12.9
|
CAS
Hex Flange, Special
|
| 8. |
J933384
|
[1] |
REAR COVER
|
CAS
Retainer - Seal
|
| 9. |
J914301
|
[1] |
GASKET
|
CAS
Rear Cover Retainer Superseded by part number: 87447962
|
| 10. |
87409160
|
[8] |
SCREW,Hex, M6 x 1 x 16mm, Cl 10.9
|
CAS
Hex Flange, M6 x 16 G10.9
|
| 11. |
J945930
|
[6] |
BEARING SET
|
CAS
Main, Upper and Lower Set, Standard
|
| 11. |
J945931
|
[6] |
BEARING SET
|
CAS
Main, Upper And Lower Set, 0.25 mm Undersize
|
| 11. |
J945932
|
[6] |
BEARING SET
|
CAS
Main, Upper And Lower Set, 0.50 mm Undersize
|
| 11. |
J945933
|
[6] |
BEARING SET
|
CAS
Main, Upper And Lower Set, 0.75 mm Undersize
|
| 11. |
J945934
|
[6] |
BEARING SET
|
CAS
Main, Upper And Lower Set, 1.0 mm Undersize
|
| 12. |
A78027
|
[1] |
BEARING LINER
|
CAS
Main Thrust, Upper And Lower Set, Standard
|
| 12. |
J945922
|
[1] |
THRUST BEARING
|
CAS
Main Thrust, Upper and Lower Set, 0.25 mm Undersize
|
| 12. |
J945923
|
[1] |
THRUST BEARING
|
CAS
Main Thrust, Upper and Lower Set, 0.50 mm Undersize
|
| 12. |
J945924
|
[1] |
THRUST BEARING
|
CAS
Main Thrust, Upper and Lower Set, 0.75 mm Undersize
|
| 12. |
J945925
|
[1] |
THRUST BEARING
|
CAS
Main Thrust, Upper and Lower Set, 1.0 mm Undersize
|
| 12. |
J945926
|
[1] |
THRUST BEARING
|
CAS
Main Thrust, Upper and Lower Set, Standard JourNal Diameter, 0.25 mm Oversize Thrust Width
|
| 12. |
J945927
|
[1] |
THRUST BEARING
|
CAS
Main Thrust, Upper and Lower Set, Standard Journal Diameter, 0.50 mm Oversize Thrust Width
|
| 12. |
J945928
|
[1] |
THRUST BEARING
|
CAS
Main Thrust, Upper and Lower Set, 0.50 mm Undersize Journal Diameter, 0.50 mm Oversize Thrust Width
|
| 13. |
J918113
|
[1] |
SHIELD,74.73mm ID x 91.7mm OD x 6mm Thk
|
CAS
Dust
|
| 14. |
A77790
|
[1] |
SEAL KIT
|
CAS
Oil, Crankshaft Front
|
| 19. |
A77808
|
[1] |
SERVICE KIT
|
CAS
Wear Sleeve, Crankshaft Front Superseded by part number: A77808AM
|
| 23. |
J924987
|
[1] |
SHIELD,77.14mm ID x 89.38mm OD x 6.35mm Thk
|
CAS
Dust
|
| 24. |
J934486
|
[1] |
SERVICE KIT
|
CAS
Oil Seal, Crankshaft Rear Superseded by part number: 87339552
|
| 27. |
A77810
|
[1] |
SERVICE KIT
|
CAS
Wear Sleeve, Crankshaft Rear Superseded by part number: A77810AM
|
