| . . | YM02H00004F1 | [1] | HYD LINES, LOW | |
| A1. | YM02H01023P1 | [1] | RIGID TUBE,321.5, 150.3 mm L | KOB |
| A2. | YM02H01024P1 | [1] | RIGID TUBE,355.5, 150.3 mm L | KOB |
| A3. | YM02H01025P1 | [1] | RIGID TUBE,253.5, 178.4 mm L | KOB |
| A4. | YM02H01026P1 | [1] | TUBE,287.5, 178.4 mm L | KOB |
| A5. | YM02H01027P1 | [1] | TUBE,257.2, 172.9 mm L | KOB |
| A6. | YM02H01028P1 | [1] | TUBE,257.2, 172.9 mm L | KOB |
| A7. | YM02H01029P1 | [1] | RIGID TUBE,1394.5, 539.6 mm L | KOB |
| A8. | YM02H01030P1 | [1] | RIGID TUBE,1394.5, 539.6 mm L | KOB |
| A9. | YM02H01031P1 | [1] | RIGID TUBE,1466, 511.5 mm L | KOB |
| A10. | YM02H01032P1 | [1] | RIGID TUBE,1466, 511.5 mm L | KOB |
| A11. | YM02H01033P1 | [1] | RIGID TUBE,1282.5, 535 mm L | KOB |
| A12. | YM02H01034P1 | [1] | RIGID TUBE,1282.5, 535 mm L | KOB |
| A13. | ZX23M04220 | [2] | HOSE ASSY. | KOB2200mm Long (86-21/32 in) |
| A14. | 2420Z1224D4 | [4] | HOSE | KOBGuard -- ID 22 x OD 26 x 300mm Long (11-13/16 in) |
| A15. | PY01P01043D3 | [10] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| A16. | ZA23B22000 | [6] | HYD CONNECTOR | KOBM30x1.50x38mm Long |
| A17. | YM02H01013P1 | [2] | CLAMP | KOB |
| A18. | YM02H01014P1 | [2] | CLAMP | KOB |
| A19. | ZS28C10040 | [4] | CAP,Hex Socket Head, M10 x 40mm | KOBScrew -- M10x1.50x40mm |
| A20. | ZW26K10000 | [4] | LOCK WASHER | KOBLock -- ID 10 x OD 15.7 x Th 2.5mm Superseded by part number: 12581679 |
| . . | YM19H00004F1 | [1] | HYD LINES, SWIVEL | |
| B1. | 2444Z2320 | [4] | ELEC CONNECTOR | KOB1"PF-M30x1.50x48mm Long |
| B2. | ZH22X04000 | [2] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| B2-1. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| B3. | ZA23F22008 | [2] | HYD CONNECTOR | KOB1/2" PT - M30x1.50 x 43mm Long |
| B4. | ZD12P02900 | [4] | O-RING | KOBID 28.70 ± 0.29 x OD 35mm |
| B5. | ZD12P01800 | [2] | O-RING | KOBID 17.8mm x OD 20.2mm |
| . . | YM12H00003F1 | [1] | LINE | KOBHYD LINES, PROPEL |
| C1. | ZH22X04000 | [2] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| C1-1. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| C2. | ZA23F22012 | [4] | HYD CONNECTOR | KOB3/4"PF - M30x1.50 x 46mm Long |
| C3. | ZA23F22008 | [2] | HYD CONNECTOR | KOB1/2" PT - M30x1.50 x 43mm Long |
| C4. | ZD12P02400 | [4] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| C5. | ZD12P01800 | [2] | O-RING | KOBID 17.8mm x OD 20.2mm |
