卡特零件查询（735） 122-1248: BASE GP-VALVE COVER & INJ HARN
广数供应链运营团队, 15 02月, 2025，浏览：
156 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 8H-3127 | [6] | BOLT(1/4-20X0.75-IN) | |
| 2. | 4F-7957 | [2] | BOLT(1/4-20X0.875-IN) | |
| 3. | 5P-0537 | [8] | WASHER-HARD(7.2X14.5X2-MM THK) | |
| 4. | 7E-6508 | [6] | CAP AS(UNIT INJECTOR) | |
| 5. | 122-1486 | [1] | HARNESS AS-WIRING(ELECTRONIC UNIT INJECTOR) | |
| | 8L-8413 | [6] | STRAP-CABLE(WHITE) | |
| | 103-8134 | [1] | KIT-RECEPTACLE(12-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| 6. | 100-5218 | [3] | CLIP | |
| 7. | 100-5219 | [3] | CLIP | |
| 8. | 177-4152 | [1] | BASE-VALVE MECHANISM COVER | |
| 9. | 9L-8925 | [14] | BOLT(5/16-18X1.25-IN) | |
| 10. | 5P-5678D | | SEAL(2.9-M) | |
| 11. | 122-1472 | [1] | BOLT(5/16-18X2.36-IN) | |
| 12. | 6V-0128 | [1] | SEAL-CONNECTOR | |
| 13. | 123-3202 | [2] | STRAP-CABLE | |
| | D | | ORDER BY THE METER |
