| . . | YM30H00010F1 | [1] | HYD LINES, PUMP (SUCTION/DELIVERY - ROTATION) | |
| 1. | ZX40U12084 | [1] | HOSE | KOB(DELIVERY P2), 840mm Long (33-1/16 in) |
| 2. | ZX40U12078 | [1] | HOSE | KOB(DELIVERY P1), 780mm Long (30-45/64 in) |
| 3. | YM30H01020P1 | [1] | HYDRAULIC HOSE | KOB(Suction) |
| 4. | ZH32X08012 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 1/2" x PF 3/4", O-Ring | KOB90° -- 1/2"PFx3/4"PFx66mm Long (Incls. O-Ring ZD12P02400) |
| 5. | YN30H01069P1 | [1] | ELBOW | KOB |
| 6. | ZD11G07500 | [1] | O-RING,74.40mm ID x 80.60mm OD x 3.10mm | KOBID 74.40 ± 0.65 x OD 80mm |
| 7. | ZD12P02600 | [4] | O-RING | KOBID 25.70 ± 0.26 x OD 32mm |
| 8. | ZE13X12000 | [4] | CLAMP | KOBHalf -- (Incls. Capscrew & Lockwasher) |
| 9. | LC52S00012P1 | [2] | SENSOR | KOBPressure (High Pressure) (replaced by LS52S00015P1), (PF3/8) Superseded by part number: YY52S00033F1 |
| 9. | LS52S00015P1 | [2] | SENSOR | KOB(New part #) (Added by SB S030-41-K003) |
| 9-0. | YY52S00033F1 | [1] | PRESSURE SWITCH | KOBKit Includes Ref 9 - 9-3 (Refer to SB S030-41-K003) |
| 9-1. | LS30H01024P1 | [1] | HYD CONNECTOR | SM(Added with new part # press switch) |
| 9-2. | ZD12P01400 | [1] | O-RING | KOBID 10.80 ± 0.18 x OD 15mm |
| 9-3. | YT42H01128P1 | [1] | 90 ELBOW | KOB(Added with new part # press switch) |
| 10. | YN03H01427P1 | [1] | CLAMP | KOB122.5x50x48mm |
| 11. | YN03H01432P1 | [2] | BUSHING,28mm ID x 56mm OD x 70mm L | KOBSplit -- ID 28 x OD 38 x 70mm Long |
| 12. | YM30H01022P1 | [1] | SUPPORT | |
| 13. | ZC16X09100 | [4] | CLIP | KOBClamp, Hose -- Min 80 x Max 101mm |
| 14. | ZS18C10075 | [2] | SCREW,Hex, M10 x 75mm | KOBM10x1.50x75mm |
| 15. | ZS28C12030 | [4] | SCREW,Hex Socket Head, M12 x 30mm | KOBScrew -- M12x1.75x30mm |
| 16. | ZW16H10000 | [3] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 17. | ZW26K12000 | [4] | LOCK WASHER | KOBID 12 x OD 17.8 x Th 2.5mm |
| 18. | ZE72X04000 | [2] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
| 19. | YY30V00039F1 | [1] | CONTROL VALVE | KOBSee Figure 07-006 |
| 20. | ZX22M08160 | [1] | HOSE | KOBPF1/2, 1600mm Long (63 in) |
| 21. | ZS18C10085 | [8] | SCREW,Hex, M10 x 85mm | KOBM10x1.50x85mm |
| 22. | ZW26X10000 | [8] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 23. | ZH22X08000 | [1] | HYD CONNECTOR | KOBPF1/2 (Incls. O-Ring ZD12P01800) |
| 24. | ZE72X06000 | [1] | PLUG | KOB3/8" PF, (Incls. O-Ring ZD12P01400) |
| 25. | ZD12P03800 | [1] | O-RING | KOBID 37.70 ± 0.37 x OD 44.7mm |
| 26. | ZS18C12025 | [2] | SCREW,Hex, M12 x 25mm | KOBM12x1.75x25mm |
| 27. | ZW16H12000 | [2] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 28. | ZE72X08000 | [2] | PLUG | KOB1/2" PF, (Incls. O-Ring ZD12P01800) |
| 29. | ZH32X08000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 1/2" x PF 1/2", O-Ring | KOBElbow, 90° -- 1/2"PT (Incls. O-Ring ZD12P01800) |
| 30. | YN03H01075P1 | [1] | BUSHING,21mm ID x 39mm OD x 50mm L | KOBSplit -- ID 21 x OD 31 x 50mm Long |
| 31. | ZC46X31014 | [1] | CLIP | KOBClamp -- Ø31mm Single Cable |
| 32. | 2444T2524 | [2] | HYD CONNECTOR | KOB1/4" PF x 50mm Long (Incls. O-Ring ZD12P01100) |
| 33. | YN30H01115P1 | [1] | FLANGE | KOB(Multi Port Block), No service parts |
| 34. | 2444R399D6 | [1] | ELBOW | KOB90° -- 1"PFx1-1/4"PFx41.5mm Long (Incls. O-Ring ZD12P03800) |
| 35. | YN30H01078D3 | [1] | HOSE | KOBL=460mm |
| 36. | ZD12P03400 | [1] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOBID 33.70 ± 0.33 x OD 40mm |
| 37. | ZS28C10045 | [4] | SCREW,Hex Socket Head, M10 x 45mm | KOBM10x1.50x45mm |
| 38. | ZW26K10000 | [8] | LOCK WASHER | KOBLock -- ID 10 x OD 15.7 x Th 2.5mm Superseded by part number: 12581679 |
| 39. | ZS28C10035 | [6] | SCREW,Hex Socket Head, M10 x 35mm | KOBScrew -- M10x1.50x35mm |
| 40. | YM06H01002D2 | [1] | HOSE | KOBPF 1, 900mm Long (35-7/16 in) |
| 41. | ZC26X18011 | [1] | CLAMP | KOB Superseded by part number: ZC26M18011 |
| 42. | ZS18C10045 | [1] | SCREW,Hex, M10 x 45mm | KOBM10x1.50x45mm |
| 43. | ZA23H18008 | [1] | HYD CONNECTOR | KOBPF1/2 |
| 44. | ZD12A01800 | [1] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOBID 18.77 ± 0.12 x OD 22.33mm |
| 45. | ZE12X20000 | [2] | CLAMP | KOBPF1/4 |
| 46. | YM30H01027P1 | [1] | TUBE | KOB |
| 47. | ZW16X10000 | [2] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
