| . . | NSS | [1] | NOT SOLD SEPARAT | CONUPPER HYDRAULIC LINES (RETURN) |
| . . | YM32H00005F1 | [1] | UPPER HYDRAULIC LINES (STD) | |
| . . | YM32H00005F2 | [1] | UPPER HYDRAULIC LINES (N&B) | |
| . . | YM32H00005F3 | [1] | UPPER HYDRAULIC LINES (EXTRA) | |
| . . | YM32H00005F4 | [1] | UPPER HYDRAULIC LINES (EXTRA OR ROT + N&B) | |
| 1. | YM32H01032P1 | [1] | RIGID TUBE | KOB |
| 2. | YM32H01031P1 | [1] | RIGID TUBE,868, 387.5 mm L | KOB |
| 3. | YM32H01026P1 | [1] | TUBE | KOB |
| 4. | YM32H01036P1 | [1] | U-BRACKET | KOBBLOCK |
| 5. | ZX21M08070 | [1] | HOSE ASSY. | KOBPF1/2, 700mm Long (27-35/64 in) |
| 6. | ZX21M08110 | [1] | FLEXIBLE HOSE | KOBPF1/2, 1100mm Long (43-19/64 in) |
| 7. | ZX32M08050 | [1] | HOSE | KOBPF1/2L=500mm |
| 8. | ZG15F05100 | [1] | COUPLING | KOB |
| 10. | ZG15F04300 | [3] | COUPLING | KOB |
| 11. | YN21V00006F1 | [1] | VALVE | KOB |
| 12. | YN21V00007F1 | [1] | CHECK VALVE | KOB |
| 13. | ZH22X08012 | [1] | HYD CONNECTOR | KOB1/2"PFx3/4"PFx52mm Long |
| 13-1. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 14. | HH55X08006G1 | [1] | TEE | KOB(2) 1/2" PF x 3/8" PF x 70mm Long (Incls. O-Ring ZD12P01400) |
| 14-1. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 15. | 2444Z2686 | [1] | TEE | KOB2-PF1/2-PF3/4 |
| 15-1. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 16. | ZE72X16000 | [1] | PLUG | KOB(Incls. O-Ring ZD12P02900) PF1, FOR F1,F3 Only |
| 17. | ZD11G04500 | [1] | O-RING,44.40mm ID x 50.60mm OD x 3.10mm | KOBID 44.40 ± 0.41 x OD 50mm |
| 18. | YM32H01025P1 | [1] | SUPPORT | KOBSUPPORT |
| 19. | YM32H01024P1 | [1] | SUPPORT | KOBSUPPORT |
| 20. | YM32H01035P1 | [1] | SUPPORT | KOBSUPPORT |
| 21. | YN32H01035P1 | [1] | CLAMP | KOB |
| 22. | 2432T5299 | [1] | CLAMP | KOB |
| 23. | 45Z91D84 | [2] | O-RING | KOBID 56.74 ± 0.25 OD 63.80mm |
| 24. | 2420T2948D20 | [2] | U-BOLT | KOBM08x1.25x ID 44x 80mm Long |
| 25. | YN03H01075P1 | [1] | BUSHING,21mm ID x 39mm OD x 50mm L | KOBSplit -- ID 21 x OD 31 x 50mm Long |
| 26. | ZC46X31014 | [1] | CLIP | KOBClamp -- Ø31mm Single Cable |
| 27. | ZW16K12000 | [8] | WASHER | KOBID 13 x OD 21 x Th 2.5mm |
| 28. | YN02B01031D2 | [2] | SPACER | KOB |
| 29. | ZS18C12035 | [4] | SCREW,Hex, M12 x 35mm | KOBM12x1.75x35mm |
| 30. | ZS18C10025 | [1] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 31. | ZS18C10055 | [2] | SCREW,Hex, M10 x 55mm | KOBM10x1.50x55mm |
| 32. | HS18C10095G1 | [4] | SCREW | KOB |
| 33. | ZS18C12040 | [2] | SCREW,Hex, M12 x 40mm | KOBM12x1.75x40mm |
| 34. | ZS28C12025 | [4] | CAP,Hex Socket Head, M12 x 25mm | KOBScrew -- M12x1.75x25mm |
| 35. | ZW16H08000 | [4] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| 36. | ZW16H10000 | [8] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 37. | ZW16H12000 | [8] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 38. | ZN18C08007 | [8] | NUT | KOBM08x1.25mm |
| 39. | ZN18C10008 | [1] | NUT | KOBM10x1.50mm |
| 40. | ZX31M08070 | [1] | HOSE ASSY. | KOBPF1/2L=700mm |
| 41. | HH25R12012G3 | [1] | HYD CONNECTOR | KOB3/4"PFx42mm Long (Incls. O-Ring 237-6012) |
| 41-1. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 42. | ZS28C12035 | [4] | CAPSCREW,Hex Socket Head, M12 x 35mm | KOBSCREW M12x1.75x35mm |
| 43. | ZE72X08000 | [1] | PLUG | KOB1/2" PF, (Incls. O-Ring ZD12P01800), FOR F1,F2 Only |
| 44. | YM32H01034P1 | [1] | SUPPORT | KOBSUPPORT |
| 45. | YN32H01066P1 | [1] | CLAMP | KOB94x38x31mm |
| 46. | ZS18C12065 | [1] | SCREW,Hex, M12 x 65mm | KOBM12x1.75x65mm |
| 47. | ZN18C12010 | [1] | NUT | KOBM12x1.75mm |
