| . . | YM64H00013F1 | [1] | CONTROL LINES, BLOCK | |
| 1. | YM64H01013P2 | [1] | BLOCK ASSY. | KOBBLOCK ASSY |
| 2. | YX52S00010P1 | [6] | SENSOR | KOBPressure (PF 1/4) Superseded by part number: LC52S00019P1 |
| 2-2. | ZD12P01100 | [6] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 3. | ZH32X06000 | [13] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| 3-1. | ZD12P01400 | [13] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 4. | YN21V00005F2 | [2] | CHECK VALVE | KOBCheck, PF 3/8, (Incls. O-Ring ZD12P01400), THROTTLING |
| 5. | 2444Z3155 | [3] | 90 ELBOW,PF 3/8" Fem x PF 3/8" Male | KOB90° -- (PF 3/8) (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 Superseded by part number: YT42H01128P1 |
| 6. | ZS18C10025 | [2] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 7. | ZW16H10000 | [2] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 8. | YN64H01018P1 | [1] | GROMMET | KOB |
| 9. | PY01P01043D6 | [5] | CABLE TIE,4.80mm W x 383mm L | KOBWire Ties -- 368mm Long |
| 10. | YN64H01068D1 | [1] | RUBBER | KOB |
| 11. | 2420R537D100 | [1] | HOSE,9.60mm ID x 1000mm L | KOBPF 3/8 |
| 12. | 2420R537D140 | [1] | HOSE ASSY.,9.60mm ID x 1400mm L | KOB3/8 PF, 1400mm Long (55-7/64 in) |
| 13. | 2420R537D110 | [1] | HOSE ASSY.,9.60mm ID x 1100mm L | KOBPF3/8 L=1100mm Superseded by part number: HX21E06110DX |
| 14. | YN21V00005F3 | [1] | CHECK VALVE | KOBCheck, PF 3/8, (Incls. O-Ring ZD12P01400),THROTTLING |
| 15. | ZE72X04000 | [2] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
| 16. | 2420R537D130 | [1] | HOSE,9.60mm ID x 1300mm L | KOBPF 3/8 Superseded by part number: HX21E06130DX |
| 17. | 2420R537D090 | [1] | FLEXIBLE HOSE,9.60mm ID x 900mm L | KOB900mm Long (35-7/16 in) |
| 18. | 2420R537D095 | [1] | HOSE,9.60mm ID x 950mm L | KOBPF 3/8, 950mm Long (37-25/64 in) |
| 19. | 2420R537D125 | [1] | HOSE,9.53mm ID x 1250mm L | KOBPF 3/8 |
| 20. | 2420R537D145 | [1] | HOSE,9.53mm ID x 1450mm L | KOBPF 3/8 |
| 21. | YN64H01068DD | [1] | RUBBER | KOBL=170mm |
