| . . | NSS | [1] | NOT SOLD SEPARAT | CONCONTROL LINES-MAIN |
| . . | YM06H00007F1 | [1] | CONTROL LINES-MAIN (STD) | |
| . . | YM06H00007F2 | [1] | CONTROL LINES- MAIN (N&B) | |
| . . | YM06H00007F3 | [1] | CONTROL LINES-MAIN (BREAKER) | |
| . . | YM06H00007F4 | [1] | CONTROL LINES- MAIN (STD w/BOOM SAFETY) | |
| . . | YM06H00007F5 | [1] | CONTROL LINES-MAIN (N&B w/BOOM SAFETY) | |
| . . | YM06H00007F6 | [1] | CONTROL LINES-MAIN (BREAKBR w/BOOM SAFETY) | |
| . . | YM06H00007F7 | [1] | CONTROL LINES-MAIN (STD w/BOOM ARM SAFETY) | |
| . . | YM06H00007F8 | [1] | CONTROL LINES-MAIN (N&B w/BOOM ARM SAFETY) | |
| . . | YM06H00007F9 | [1] | CONTROL LINES-MAIN (BREAKBRw/BOOMARM SAFETY) | |
| 1. | 2444Z2891 | [2] | HYD CONNECTOR | KOB(PF3/8) (Incls. O-Ring ZD12P01400) |
| 2. | ZH22X04006 | [7] | HYD CONNECTOR | KOB(PF1/4 - PF3/8)(Incls. O-Ring 237-6006), FOR F1 & F4 Only |
| 3. | ZH22X06000 | [9] | HYD CONNECTOR | KOB(PF3/8)(Incls. O-Ring ZD12P01400), FOR F1, F2,F3,F7,F8 & F9 Only |
| 4. | ZH32X04000 | [5] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004), FOR F1,F2,F4,F5,F7,&F8 Only |
| 5. | ZH32X04006 | [7] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 3/8", O-Ring | KOB90° -- 1/4"x3/8"PF (Incls. O-Ring 237-6006 Alternate ZD12P01400), FOR F1,F4,F8,&F9 Only |
| 6. | ZH32X06000 | [3] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006, FOR F1,F2,&F3 Only |
| 7. | HH55Q06006G1 | [5] | TEE | KOB3/8" PF (Incls. O-Ring ZD12P01400), FOR F1,F2,&F3 Only |
| 8. | ZE72X06000 | [1] | PLUG | KOB3/8" PF, (Incls. O-Ring ZD12P01400), FOR F1 TO F6 Only |
| 9. | 2444Z2336 | [2] | TEE | KOBTee -- 1/4"x3/8"x3/8"PF (Incls. O-Ring ZD12P01100), FOR F1,F2,F4,F5,F7,&F8 ONLY |
| 10. | YX52S00010P1 | [1] | SENSOR | KOBPressure (PF 1/4) Superseded by part number: LC52S00019P1 |
| 11. | YN06H01017P1 | [1] | HYD CONNECTOR | KOB3/8" PF - 3/8" PF x 35mm Long (Incls. O-Rings ZD12P01400) |
| 12. | 2444Z3711 | [1] | HYD CONNECTOR | KOB(PF3/8 L=46mm)(Incls. O-Ring ZD12P01400) |
| 13. | ZH22X04000 | [2] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| 14. | 2420R349D085 | [2] | HOSE,6.35mm ID x 850mm L | KOB850mm Long (33-29/64 in) |
| 15. | HH55Q04004G1 | [1] | TEE,1/4" ORB x 1/4" JIC x 1/4" JIC | KOB1/4" PF (Incls. O-Ring ZD12P01100) |
| 16. | 2444Z3943 | [1] | ELEC CONNECTOR | KOB3/8" PF - 3/8"PFx 35mm Long (Incls. O-Ring ZD12P01400) |
| 17. | 2420R349D065 | [2] | HOSE,650.00 mm | KOBPF 1/4, 650mm Long (25-1/2 in) Superseded by part number: HX21E04065DX |
| 18. | PY01P01043D3 | [1] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 19. | 2420R349D030 | [2] | HOSE,300.00 mm | KOBPF1/4 |
| 20. | 2420R349D080 | [3] | HOSE,6.35mm ID x 800mm L | KOBPF1/4 800mm Long (31-1/2 in) |
| 21. | 2420R349D036 | [1] | HOSE | KOB(PPI/4L=360mm) Superseded by part number: 2420R349D040 |
| 22. | 2420R349D040 | [1] | HOSE,6.35mm ID x 400mm L | KOB1/4" PF, 400mm Long (15-3/4 in) |
| 23. | 2444T2524 | [1] | HYD CONNECTOR | KOB1/4" PF x 50mm Long (Incls. O-Ring ZD12P01100) |
