现代零件查询35/40/45DS/50DA-7E MAST HYD PIPING(TS-MAST,50DA-7E)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
128 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 4. |
31FV-06500
|
[2] |
VALVE-DOWN SAFETY
|
|
| 5. |
33HD-80510
|
[1] |
CONNECTOR-WELD
|
|
| 6. |
3DFV-81200
|
[1] |
TEE WA
|
|
| 7. |
3DFV-81100
|
[1] |
PIPE WA
|
|
| 8. |
P910-084007
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 9. |
P910-084048
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 9. |
P910-084052
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 9. |
P910-084056
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 9. |
P910-084058
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 9. |
P910-084062
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 9. |
P910-084066
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 9. |
P910-084073
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 9. |
P910-084080
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 9. |
P910-084087
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 10. |
S520-027000
|
[4] |
CLAMP-HOSE
|
|
| 11. |
S543-240002
|
[1] |
CLAMP-TUBE
|
|
| 12. |
904807334
|
[1] |
HOSE-RETURN
|
|
| 12. |
904807327
|
[1] |
HOSE-RETURN
|
|
| 12. |
904807320
|
[1] |
HOSE-RETURN
|
|
| 12. |
904807303
|
[1] |
HOSE-RETURN
|
|
| 12. |
904807304
|
[1] |
HOSE-RETURN
|
|
| 12. |
904807329
|
[1] |
HOSE-RETURN
|
|
| 12. |
904807307
|
[1] |
HOSE-RETURN
|
|
| 12. |
904807310
|
[1] |
HOSE-RETURN
|
|
| 12. |
904807312
|
[1] |
HOSE-RETURN
|
|
| 13. |
904807304
|
[1] |
HOSE-RETURN
|
|
| 13. |
904807321
|
[1] |
HOSE-RETURN
|
|
| 13. |
904807305
|
[1] |
HOSE-RETURN
|
|
| 13. |
904807306
|
[1] |
HOSE-RETURN
|
|
| 13. |
904807308
|
[1] |
HOSE-RETURN
|
|
| 13. |
904807341
|
[1] |
HOSE-RETURN
|
|
| 13. |
904807311
|
[1] |
HOSE-RETURN
|
|
| 13. |
904807313
|
[1] |
HOSE-RETURN
|
|
| 13. |
904807316
|
[1] |
HOSE-RETURN
|
|
| 14. |
S037-102026
|
[5] |
BOLT-W/WASHER
|
|
| 15. |
S552-102370
|
[4] |
CLAMP-BAND
|
|
| 16. |
31FB-80080
|
[4] |
CLAMP-HOSE
|
|
| 17. |
61HD-18042
|
[2] |
CLAMP-CYL
|
|
| 18. |
61HD-18130
|
[2] |
CLAMP WA-CYL
|
|
| 19. |
S037-103026
|
[4] |
BOLT-W/WASHER
|
|
| 20. |
S037-102526
|
[4] |
BOLT-W/WASHER
|
|
| 21. |
31FE-80010
|
[1] |
TEE-RETURN
|
|
| 22. |
3DFV-81600
|
[1] |
CONNECTOR
|
|
| 22. |
3DFV-81601
|
[1] |
CONNECTOR
|
|
| 23. |
3FFQ-80500
|
[2] |
PULLEY-HOSE
|
|
| 23-1. |
33HH-80510
|
[1] |
BEARING
|
|
| 24. |
S017-120506
|
[2] |
BOLT-HEX
|
|
| 25. |
S411-120006
|
[2] |
WASHER-SPRING
|
|
| 26. |
S441-120006
|
[2] |
WASHER-HARDENED
|
|
| 27. |
31FV-90300
|
[2] |
PIN-HOSE PULLEY
|
|
| 28. |
63FH-18500
|
[4] |
SHIM(0.5T)
|
|
| 29. |
63FH-18530
|
[2] |
SHIM(1.0T)
|
|
| 30. |
33HD-80210
|
[1] |
CONNECTOR
|
|
