凯斯零件查询(FLX3510) - FLOATER (8/04-8/06) (01-020[01]) - DOOR GROUP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
475 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
391880A3
|
[1] |
DOOR ASSY.
|
CAS
Superseded by part number: 391880A4
|
| 2. |
388764A1
|
[2] |
BUSHING
|
CAS
Flanged Superseded by part number: 87429877
|
| 3. |
R51754
|
[1] |
STRIKER
|
CAS
Door Striker
|
| 4. |
231-5347
|
[1] |
FLANGE NUT,7/16"-14, G5
|
CAS
Superseded by part number: 86637767
|
| 5. |
1280263C1
|
[1] |
CYLINDER ASSY.
|
IH
strut, gas
|
| 6. |
9849996
|
[2] |
CLIP
|
WIN
Retainer Ball Stud
|
| 7. |
86639312
|
[2] |
WASHER,13.5mm ID x 20mm OD x 2mm Thk
|
FAR
|
| 8. |
130003
|
[2] |
COTTER PIN,3mm OD x 30mm OAL
|
ZED
|
| . . |
60-7083T1
|
[1] |
HANDLE
|
L
Cab Door Superseded by part number: 9707331
|
| . . |
382777A1
|
[1] |
LATCH
|
CAS
door
|
| . . |
359680A2
|
[1] |
COVER
|
BN
door latch
|
