| . . | YN02C00103F2 | [1] | CAB | KOB |
| 3. | YN50C00003F1 | [1] | WINDOW ASSY | KOB Superseded by part number: YN50C00003F4 |
| 4. | YN02C01913F1 | [1] | PLATE | KOB |
| 5. | YT02C01066P1 | [1] | STOP | KOB |
| 6. | YN02C02095P1 | [2] | STOP | KOB |
| 7. | YT02C01334P1 | [2] | HOLDER | KOB |
| 8. | YT02C01081D1 | [4] | SEAL | KOB |
| 9. | YN02C02128P1 | [2] | STOP | KOB |
| 10. | YT02C01070P1 | [2] | RUBBER SLEEVE | KOB |
| 11. | YN02C02147P1 | [1] | RUBBER SLEEVE | KOB |
| 12. | YN02C01953P1 | [1] | RAIL ASSY. | KOB Superseded by part number: YN02C01953P2 |
| 13. | YN02C01954P1 | [1] | RAIL ASSY. | KOB |
| 14. | YN02C01955P1 | [1] | RAIL ASSY. | KOB |
| 16. | YT02C01232F1 | [2] | LOCK | KOB |
| 16-1. | YT02C01232S001 | [1] | BASE | KOB |
| 16-2. | YT02C01232S002 | [1] | HANDLE | KOB |
| 16-3. | YT02C01232S003 | [1] | COVER | KOB |
| 16-4. | YT02C01232S004 | [1] | SPRING | KOB |
| 17. | YN02C01742P1 | [2] | CATCH | KOB |
| 18. | YT02C01086P1 | [2] | GAS STRUT | KOB |
| 19. | YT51C01077D1 | [1] | SPACER | KOB |
| 20. | 2420Z1227D8 | [2] | SCREW | KOBM06x1.0x12mm |
| 21. | 2420R372D14 | [2] | GROMMET | KOB |
| 22. | ZR36X00800 | [1] | SNAP RING | KOB |
| 23. | ZS18C08030 | [1] | SCREW,Hex, M8 x 30mm | KOBM08x1.25x30mm |
| 24. | YT02C01235P1 | [1] | GROMMET | KOB |
| 25. | YT50S00004P1 | [1] | SWITCH | KOB |
| 26. | YN03M01159P1 | [1] | GROMMET | KOB |
| 27. | YT02C01109F1 | [1] | CATCH | KOB Superseded by part number: YN02C04422F1 |
| 28. | YT02C01124P1 | [1] | COVER | KOB |
| 29. | YN02C02117P1 | [1] | LEVER | KOB Superseded by part number: YN02C02117P2 |
| 30. | YT02C01207P1 | [1] | SPRING | KOB |
| 31. | YT02C01276P1 | [1] | COVER | KOB |
| 32. | YN02C01823P1 | [2] | STOP | KOB |
| 33. | YT02C01233P1 | [1] | CAP | KOB |
| 34. | 2418Z726D3 | [2] | WASHER, LOCK | KOBID 06 x OD 12.2 x Th 1.5mm Superseded by part number: ZW26X06000 |
| 35. | YN02C01811P1 | [2] | PLATE | KOB |
| 36. | YN02C01656P1 | [1] | LOCK ASSY | KOB |
| 37. | YN02C01764P1 | [2] | RUBBER SLEEVE | KOB |
| 38. | YT51C01021P1 | [1] | HOOK | KOB |
| 39. | ZM66C05012 | [4] | BOLT | KOBM05x0.8x12mm (Incls. Washer & Lockwasher) |
| 40. | YN02C01763P1 | [2] | BRACKET | KOB |
| 41. | YT02C01261D1 | [5] | PLATE | KOB |
| 42. | YT54C00001P1 | [1] | WINDSHIELD WASHER | KOBWINDSHIELD WASHER |
| 43. | YT02C01126D1 | [1] | TUBE | KOB3500mm Long (137-51/64 in) |
| 44. | YT02C01274P1 | [1] | COVER | KOB |
| 45. | YN02C01567P1 | [1] | GLASS | KOB |
| 46. | YN02C01787P1 | [1] | GLASS | KOB |
| 47. | YT02C01390P1 | [4] | WASHER,9mm ID x 20mm OD x 0.8mm Thk | KOBID 09 x OD 20 x Th 0.8mm |
| 48. | YN55C00005P1 | [1] | SUN VISOR | KOB |
| 50. | YN02C02082P1 | [1] | GLASS | KOB |
| 51. | YN02C01794P1 | [1] | GLASS | KOB |
| 52. | YN02C01812P1 | [3] | SPACER,10mm ID x 20mm OD x 4mm L | KOB |
| 53. | YN02C01875D1 | [8] | SCREW | KOBM05x0.8x16mm Long |
| 55. | YT02C01330F2 | [1] | STOP | KOBAssembly |
| 55-1. | YT02C01304P1 | [1] | STOP | KOBM10x1.25x36mm Long -- Replaced by YN02C02963P1 Superseded by part number: YN02C02963P1 |
| 55-1. | YN02C02963P1 | [1] | PLUG | KOBStop -- M10x1.25x43mm Long |
| 55-2. | YT02C01306P1 | [1] | RUBBER | KOB |
| 55-4. | YT02C01307P1 | [1] | PLATE | KOB |
| 55-5. | YN50E00006P1 | [1] | SWITCH ASSY | KOB |
| 56. | YN02C02087P1 | [1] | WEATHERSTRIP | KOB Superseded by part number: YN02C02087P2 |
| 57. | YN02C01741P1 | [1] | SEAL | KOB Superseded by part number: YN02C01741P2 |
| 58. | YN02C02019P1 | [1] | PAD | KOB |
| 59. | YN02C01888P1 | [2] | PACKING | KOB |
| 60. | YT02C01129P1 | [2] | COVER | KOB |
| 61. | YR21C01161P1 | [4] | WASHER,9mm ID x 22mm OD x 2.3mm Thk | KOBID 09 x OD 22 x Th 2.3mm |
| 62. | YN02C01761P1 | [1] | HARNESS | KOB |
| 63. | YN02C01821P1 | [1] | RUBBER | KOB |
| 64. | 2418Z725D3 | [5] | WASHER | KOBID 06 x OD 11.5 x Th 1.6mm |
| 65. | YT54S00001P1 | [1] | ANTENNA | KOB Superseded by part number: YT54S00018F1 |
| 66. | YT02C01134P1 | [1] | HOOK | KOB |
| 67. | YN01T01012F1 | [1] | HAMMER | KOB |
| 68. | YT80S00001P1 | [1] | LIGHT | KOB Superseded by part number: 2456Z322F1 |
| 69. | YN02C01790P1 | [1] | HANDLE | KOB |
| 70. | ZM66C06016 | [18] | BOLT | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) |
| 71. | 2418T12753 | [1] | WASHER | KOBID 09 x OD 30 x Th 3.2mm |
| 72. | YN17M01033D3 | [3] | SCREW | KOBM05x10mm |
| 73. | YT02C01161P1 | [2] | CLAMP | KOB |
| 74. | YN02C01668P1 | [3] | RETAINER | KOB |
| 75. | YT02C01136P1 | [2] | STOP | KOB |
| 76. | YT02C01140P1 | [2] | STOP | KOB |
| 77. | ZS32T40020 | [2] | SCREW | KOBM04x20mm Self-Taper |
| 78. | YN53C00011P1 | [1] | WIPER | KOBMotor Assembly -- No service competes Superseded by part number: YN53C00012F2 |
| 79. | YN53C01003F1 | [1] | WIPER ARM | KOB-- is a complete arm & wiper assembly -- Incls. Refs. 79-1 & 79-2 |
| 79-1. | YN53C01003S001 | [1] | WIPER ARM | KOB-- is just the wiper arm, 505.6mm Long (19-29/32 in), Not Shown |
| 79-2. | YN53C01003S002 | [1] | WIPER BLADE | KOB-- is just the wiper blade, 600mm Long (23-5/8 in), Not Shown Superseded by part number: 47669054 |
| 80. | YN02C01820P1 | [6] | CLIP | KOB |
| 81. | YN02C01294P1 | [1] | STOP | KOB |
| 82. | ZM27C10025 | [3] | BOLT | KOBM10x1.50x25mm (Incls. Washer & Lockwasher) |
| 83. | YN02C01292P1 | [4] | PLUG | KOBOD 8 x 14mm Long (Nylon) |
| 84. | YN02C01876D1 | [8] | SCREW | KOBM05x12mm Self-Taper |
| 85. | YT02C01261D3 | [9] | PLATE | KOB |
| 86. | YN02C01914P2 | [1] | WASHER | KOB |
| 87. | YN02C01825P1 | [1] | SEAL,2050mm L | KOB |
| 88. | ZM46C06020 | [4] | BOLT | KOBM06x1.0x20mm (Incls. Washer & Lockwasher) |
| 89. | ZN18F10008 | [4] | NUT | KOBM10x1.25mm |
| 90. | ZW16X10000 | [2] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 91. | YN02C02118P1 | [1] | FOAM INSULATION | KOB |
| 92. | YT02C01333P1 | [2] | WASHER | KOB |
| 93. | YN02C02119P1 | [1] | FOAM INSULATION | KOBINSULATION |
| 94. | YR11M01038D1 | [8] | NUT | KOB |
| 95. | YN02C02148P1 | [1] | RUBBER | KOB |
| 96. | YN02C01652P1 | [2] | HINGE | KOB |
| 97. | YN02C01669P1 | [3] | PACKING | KOB |
| 98. | YN02C01736F3 | [1] | CABLE ASSY. | KOB Superseded by part number: YN02C02353F1 |
| 98-1. | YN02C01736S001 | [1] | BRACKET | KOB |
| 98-2. | YN02C01736S002 | [1] | SPRING | KOB Superseded by part number: 72209640 |
| 98-3. | YN02C01736S003 | [1] | SHAFT | KOB |
| 98-4. | YN02C01736S004 | [1] | SHAFT | KOB |
| 98-5. | YN02C01736S005 | [2] | SHAFT | KOB |
| 98-6. | ZR36X00600 | [2] | SNAP RING | KOBE-Ring -- Shaft 06mm x OD 12mm |
| 98-20. | YN02C01736S020 | [1] | CABLE | KOB Superseded by part number: YN02C02353F1 |
| 99. | ZR36X00600 | [4] | SNAP RING | KOBE-Ring -- Shaft 06mm x OD 12mm |
| 100. | YT02C01261D2 | [3] | PLATE | KOB |
| 101. | ZW11X10000 | [6] | WASHER | KOBID 10 x OD 21 x Th 2.0mm Superseded by part number: ZW16X10000 |
| 102. | ZW22X10000 | [6] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 103. | ZN13C10008 | [6] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 104. | PY21V01001P1 | [1] | CHECK VALVE | KOB |
| 105. | ZS68C08025 | [2] | SCREW,Pan, M4 x 12mm | KOBScrew -- M08x1.25x25mm |
| 106. | YT02C01229P1 | [2] | WASHER | KOBStar Lock -- ID 08.40 ± 0.30 x OD 16 x Th 0.6mm |
| 107. | YN02C01824P1 | [2] | PIN,8mm OD x 15.8mm L | KOB |
| 108. | ZS31C05010 | [4] | BOLT,Phillips Drive, Pan HD, M5 x 10mm | KOBM05x0.8x10mm |
| 109. | 2420Z1227D4 | [5] | SCREW | KOBM06x1.0x20mm |
| 110. | YT02C01275P1 | [1] | LABEL | KOB |
| 111. | 2420T4505 | [6] | WASHER,7mm ID x 16mm OD x 1mm Thk | KOBID 07 x OD 16 x Th 1.0mm |
| 112. | ZS32T40012 | [4] | SCREW | KOBM04x12mm Self-Taper |
| 113. | YN02C01962P1 | [1] | FOAM INSULATION | KOB |
| 114. | ZW26X08000 | [1] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 115. | YT02C01280P1 | [1] | SPACER | KOB |
| 116. | ZM22C08020 | [4] | BOLT | KOBM08x1.25x20mm (Incls. Washer & Lockwasher) |
| 119. | YN02C01880P1 | [4] | RIVET,8.1mm OD x 25mm L | KOB |
| 120. | ZW16K05000 | [1] | WASHER | KOBID 05 x OD 10 x Th 1.0mm |
| 121. | 2420R372D8 | [1] | GROMMET | KOB |
| 122. | YT02C01268P1 | [2] | WASHER | KOB |
| 123. | YN02C02153D1 | [2] | SHIM | KOBSHIM |
| 127. | YN02C00106P1 | [1] | CAB ASSY (NOT SERVICIEABLE) | |
| 128. | YN51C00010F2 | [1] | DOOR ASSY. | KOB |
| 129. | YN02C02002P1 | [1] | ROOF | KOB |
| 130. | YN02C02136P1 | [1] | GLASS | KOB |
| 131. | YT02C01514D2 | [1] | SEAL | KOB Superseded by part number: YR02C01511D2 |
| 135. | YT02C01515D1 | [1] | TRIM PANEL | KOB Superseded by part number: YT02C01515D2 |
| 136. | YT02C01115D3 | [1] | RUBBER SLEEVE | KOB |
| 137. | YN02C02186P1 | [2] | SPACER | KOB |
