| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM22E00012F1 | [1] | CONTROLLER GROUP | |
| A1. | YN22E01147P2 | [1] | BOX | KOBBOX |
| A2. | YN22E01141P1 | [1] | PLATE | KOB |
| A4. | YM22E00008F1 | [1] | ECU | KOBProgrammed Superseded by part number: YN22E00149F3 |
| A5. | YT24E00001F1 | [1] | RELAY | KOB |
| A6. | EN24S00008P1 | [3] | RELAY | KOB(5 Spade Relay) |
| A7. | YX50E00002F1 | [1] | SWITCH | KOB |
| A8. | YN22E01139P1 | [1] | PLATE | KOBPLATE |
| A9. | ZM66C05016 | [2] | BOLT | KOBM05x0.8x16mm (Incls. Washer & Lockwasher) |
| A10. | ZM61C06030 | [4] | BOLT | KOBM06x1.0x30mm (Incls. Washer & Lockwasher) |
| A11. | YN22M01014P1 | [1] | LABEL | KOBDecal, Swing Parking Brake Release Lock and Normal |
| A12. | ZM61C06016 | [8] | BOLT | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) |
| A13. | 2420Z699 | [1] | GROMMET | KOB |
| A14. | YM14E00004F2 | [1] | HARNESS | KOBHARNESS ASSY,C |
| A14-2. | ZS18C06016 | [2] | SCREW,Hex, M6 x 16mm | KOBM06x1.0x16mm |
| A14-3. | ZM61C06020 | [8] | BOLT | KOBM06x1.0x20mm (Incls. Washer & Lockwasher) |
| A14-4. | YN03E01001D5 | [11] | CLIP | KOB195mm Long (7-43/64 in) -- Black |
| A14-5. | ZW26X06000 | [2] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| A14-6. | ZW16X06000 | [2] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| A14-7. | YM14E01010P1 | [1] | HARNESS | KOB |
| A14-7-2. | YM73E00001F1 | [1] | FUSE | KOBFUEL ASSY |
| A14-7-2-1. | YN73E00001S001 | [1] | BASE | KOB |
| A14-7-2-2. | YN73E00001S002 | [1] | COVER | KOB |
| A14-7-2-3. | YM73E01001P1 | [1] | LABEL | KOBLABEL |
| A14-7-2-4. | 2479R655S8 | [11] | FUSE,10 Amp | KOB10 Amp Superseded by part number: 87522597 |
| A14-7-2-5. | 2479R655S9 | [9] | FUSE,20 Amp | KOB20 Amp |
| A15. | YN50S01003P1 | [1] | SWITCH | KOB |
| A16. | YN22M01013P1 | [1] | LABEL | KOB |
| A17. | LC22E01001D1 | [1] | RESISTOR,16ohm | KOB16 Ohm |
| A18. | ZM41C04016 | [1] | BOLT | KOBM04x0.7x16mm (Incls. Washer & Lockwasher) Superseded by part number: ZM46C04016 |
| . . | YN22E00145F1 | [1] | CONTROL UNIT | KOB |
| B1. | YN22E01121P1 | [1] | SUPPORT | KOBSUPPORT |
| B2. | YN22E01145P1 | [1] | SUPPORT | KOBSUPPORT |
| B3. | YN22E01149P2 | [1] | BRACKET | KOBBRACKET |
| B4. | YN25S00001P1 | [1] | TIMER | KOB |
| B5. | ZM66C06025 | [1] | BOLT | KOBM06x1.0x25mm (Incls. Washer & Lockwasher) |
| B6. | ZM32C10025 | [5] | BOLT | KOBM10x1.50x25mm (Incls. Washer & Lockwasher) |
| B7. | ZM22C10030 | [6] | BOLT | KOBM10x1.50x30mm (Incls. Washer & Lockwasher) |
| B8. | ZM66C06016 | [4] | BOLT | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) |
| B9. | YN24E00010F1 | [1] | RELAY | KOBREALY ASSY |
| B9-1. | YN24E01007P1 | [1] | PLATE | KOB |
| B9-2. | ZM61C06016 | [1] | BOLT | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) |
| B9-3. | YN77S00017P1 | [1] | CONVERTER,24V In - 13.2V Out - 7.5A | KOB Superseded by part number: YN77S00069P1 |
| B9-4. | YY24S00001P1 | [1] | RELAY | KOB Superseded by part number: YY24S00001P2 |
| B9-5. | ZM61C05016 | [2] | BOLT | KOBM05x0.8x16mm (Incls. Washer & Lockwasher) |
| A3. | VAME077148 | [1] | RELAY | KOB |
