凯斯零件查询(FLX3510) - FLOATER (8/04-8/06) (01-054[02]) - PROPEL CONTROL LEVER ASSEMBLY, COLOR, LIQUID OR FLEX-AIR Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
452 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
BN323510
|
[1] |
LEVER
|
BN
prop control
|
| 3. |
127597A1
|
[1] |
SWITCH
|
CAS
unloader auger
|
| 5. |
225350C1
|
[1] |
ELEC CONNECTOR,Male, 6 Pin
|
IH
6 pin type LY Superseded by part number: 87694152
|
| . . |
225353C1
|
[1] |
WEDGE,Lock, Black
|
IH
Type W6P Superseded by part number: 87694147
|
| 7. |
225388C1
|
[1] |
ELEC CONNECTOR,Male, 12 Pin
|
IH
12 pin type NA Superseded by part number: 87695724
|
| . . |
87055164
|
[1] |
WEDGE
|
BEL
Type W 12P Superseded by part number: 87698541
|
| . . |
260-54310
|
[1] |
SELF-TAP SCREW,Cross Pan Hd, #6 x 5/8"
|
CAS
Superseded by part number: 86637783
|
| . . |
86625127
|
[1] |
PLUG,Dome, .375" hole, Nylon
|
FAR
|
| . . |
BN2290332
|
[1] |
LOOM
|
A
Split 3/4" id #1789
|
| 13. |
NS
|
[1] |
NOT SERVICED
|
BAS
Plate Assembly, Prop Control
|
| 14. |
BN321530
|
[1] |
SWITCH
|
A
Spray On/Off
|
| 15. |
113314A2
|
[1] |
CONTROL LEVER
|
CAS
propulsion, Start Serial: 6700
|
| 16. |
BN324896
|
[2] |
SWITCH
|
BN
Assy Boom Cntrl
|
| . . |
BN50054
|
[1] |
NUT,1/4"-20, SS
|
A
|
