神钢零件查询(SK160LC-6E) - DYNAMIC ACERA EXCAVATOR 08/2004 ASN YM03U0523 (8/04-12/07) (01-065[08]) - HARNESS ASSY, UPPER FRAME (STD) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
563 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM13E00004F1 | [1] | HARNESS ASSY, UPPER FRAME (STD) | |
| 1. | YM13E01020P3 | [1] | HARNESS | KOBUPPER Superseded by part number: YM13E01020P4 |
| 2. | YM13EU1002D1 | [1] | NEG BATTERY CABLE | KOBBATTERY RELAY |
| 3. | YN13E01097P1 | [1] | CABLE | KOB400mm Long (15-3/4 in), BATTERY RELAY |
| 4. | 2486R87D1 | [1] | CABLE | KOBGROUND |
| 6. | LE13E01006P1 | [1] | HARNESS | KOB100mm Long (3-15/16 in), (Floor Plate-Ground) |
| 7. | ZW26X08000 | [5] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 8. | ZN18C08007 | [4] | NUT | KOBM08x1.25mm |
| 9. | ZS18C08016 | [1] | SCREW,Hex, M8 x 16mm | KOBM08x1.25x16mm |
| 10. | LC13E01002D1 | [1] | GROMMET | KOB |
| 11. | PY01P01043D3 | [6] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 12. | PY01P01043D5 | [1] | CABLE TIE,301mm L | KOBWire Ties -- 292mm Long |
| 13. | 2420Z1330 | [1] | GROMMET | KOB |
| 14. | 2427Z1594D006 | [1] | TRIM PANEL | KOB |
| 15. | ZW16X08000 | [1] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 16. | 2432R233D3 | [3] | CLIP | KOB50x16x60mm |
| 17. | ZM61C06012 | [2] | BOLT | KOBM06x1.0x12mm (Incls. Washer & Lockwasher) |
| 18. | 2420R372D19 | [2] | GROMMET | KOB |
| 19. | YN03E01001D5 | [6] | CLIP | KOB195mm Long (7-43/64 in) -- Black |
| 20. | 2432R233D1 | [2] | CLIP | KOB37x12x40mm |
| 25. | YM13E01028P1 | [1] | CABLE | KOBSTARTER |
